Hardware Installation - 12 -
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2) The PCIEX1_1 and PCIEX1_2 slots share bandwidth with the PCIEX4 slot. When the PCIEX4 slot
is populated with a x4 card, the PCIEX1_1 and PCIEX1_2 slots become unavailable.
(Note 3) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 4) Available functions in EasyTune may differ by motherboard model.
BIOS
2 x 8 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
(Note 4)
Support for Easy Energy Saver
Support for Smart Recovery
Support for Auto Green
Support for ON/OFF Charge
Support for Q-Share
Bundled Software
Norton Internet Security (OEM version)
Operating System
Support for Microsoft
®
Windows
®
7/Vista/XP
Form Factor
ATX Form Factor; 30.5cm x 23.0cm
Содержание
- Ga 870a ud3 1
- User s manual 1
- 2010 giga byte technology co ltd all rights reserved the trademarks mentioned in this manual are legally registered to their respective owners 3
- Copyright 3
- Disclaimer 3
- Documentation classifications 3
- Example 3
- For product related information check on our website at http www gigabyte com 3
- Identifying your motherboard revision 3
- In order to assist in the use of this product gigabyte provides the following types of documentations 3
- Information in this manual is protected by copyright laws and is the property of gigabyte changes to the specifications and features in this manual may be made by gigabyte with out prior notice no part of this manual may be reproduced copied translated transmitted or published in any form or by any means without gigabyte s prior written permission 3
- The revision number on your motherboard looks like this rev x x for example rev 1 means the revision of the motherboard is 1 check your motherboard revision before updating motherboard bios drivers or when looking for technical information 3
- Box contents optional items ga 870a ud3 motherboard layout ga 870a ud3 motherboard block diagram 4
- Chapter 1 hardware installation 4
- Chapter 2 bios setup 3 4
- Table of contents 4
- Chapter 3 drivers installation 7 5
- Chapter 4 unique features 1 5
- Chapter 5 appendix 5 5
- Box contents 6
- Optional items 6
- Ga 870a ud3 7
- Ga 870a ud3 motherboard layout 7
- Ga 870a ud3 motherboard block diagram 8
- 1 installation precautions 9
- Chapter 1 hardware installation 9
- 2 productspecifications 10
- All pci express slots conform to the pci express 2 10
- 3 1 installing the cpu 13
- 3 installing the cpu and cpu cooler 13
- 3 2 installing the cpu cooler 15
- 4 1 dualchannelmemoryconfiguration 16
- 4 installing the memory 16
- 4 2 installing a memory 17
- 5 installing an expansion card 18
- 6 back panel connectors 19
- Coaxial s pdif out connector 19
- Esata 3gb s port 19
- Ieee 1394a port 19
- Optical s pdif out connector 19
- Ps 2 keyboard or ps 2 mouse port 19
- Rj 45 lan port 19
- Usb 2 1 port 19
- Center subwoofer speaker out jack orange 20
- Line in jack blue 20
- Line out jack green 20
- Mic in jack pink 20
- Rear speaker out jack black 20
- Side speaker out jack gray 20
- Usb 3 2 port 20
- 7 internal connectors 21
- 2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 22
- Hardware installation 22 22
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 22
- With the use of the power connector the power supply can supply enough stable power to all the com ponents on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power con nector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 22
- 23 hardware installation 23
- 4 5 cpu_fan sys_fan1 sys_fan2 pwr_fan fan headers 23
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from over 23
- Fdd floppy disk drive connector 23
- Headers 23
- Heating overheating may result in damage to the cpu or the system may hang 23
- The motherboard has a 4 pin cpu fan header cpu_fan a 4 pin sys_fan1 and one 3 pin sys_ fan2 system fan headers and a 3 pin power fan header pwr_fan most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed control which requires the use of a cpu fan with fan speed control design for optimum heat dissipation it is recom mended that a system fan be installed inside the chassis 23
- These fan headers are not configuration jumper blocks do not place a jumper cap on the 23
- This connector is used to connect a floppy disk drive the types of floppy disk drives supported are 360 kb 720 kb 1 mb 1 4 mb and 2 8 mb before connecting a floppy disk drive be sure to locate pin 1 of the connector and the floppy disk drive cable the pin 1 of the cable is typically designated by a stripe of different color for purchasing the optional floppy disk drive cable please contact the local dealer 23
- A raid 0 or raid 1 configuration requires at least two hard drives if more than two hard 24
- A raid 10 configuration requires at least four hard drives and the total number of hard drives 24
- A raid 5 configuration requires at least three hard drives the total number of hard drives 24
- Does not have to be an even number 24
- Drives are to be used the total number of hard drives must be an even number 24
- Hardware installation 24 24
- Ide ide connector 24
- Must be an even number 24
- Pin no definition 24
- Please connect the l shaped end of the sata cable to your sata hard drive 24
- Sata3_0 1 2 3 4 5 sata 6gb s connectors controlled by amd sb850 south bridge 24
- The ide connector supports up to two ide devices such as hard drives and optical drives before attach ing the ide cable locate the foolproof groove on the connector if you wish to connect two ide devices remember to set the jumpers and the cabling according to the role of the ide devices for example master or slave for information about configuring master slave settings for the ide devices read the instructions from the device manufacturers 24
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standards each sata connector supports a single sata device the amd sb850 controller supports raid 0 raid 1 raid 5 raid 10 and jbod refer to chapter 5 configuring sata hard drive s for instructions on configuring a raid array 24
- 25 hardware installation 25
- A raid 0 or raid 1 configuration requires at least two hard drives 25
- Always turn off your computer and unplug the power cord before replacing the battery replace the battery with an equivalent one danger of explosion if the battery is replaced with 25
- An incorrect model 25
- Bat battery 25
- Contact the place of purchase or local dealer if you are not able to replace the battery by your 25
- Gsata2_6 7 sata 3gb s connectors controlled by gigabyte sata2 25
- Of the battery the positive side should face up 25
- Self or uncertain about the battery model 25
- The battery provides power to keep the values such as bios configurations date and time information in the cmos when the computer is turned off replace the battery when the battery voltage drops to a low level or the cmos values may not be accurate or may be lost 25
- The gigabyte sata2 supports raid 0 and raid 1 refer to chapter 5 configuring sata hard drive s for instructions on configuring a raid array 25
- The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device 25
- Used batteries must be handled in accordance with local environmental regulations 25
- When installing the battery note the orientation of the positive side and the negative side 25
- F_panel front panel header 26
- 27 hardware installation 27
- Audio signals will be present on both of the front and back panel audio connections simultane 27
- Cd_in cd in connector 27
- F_audio front panel audio header 27
- Front panel audio module refer to the instructions on how to activate ac 97 functionality via the audio software in chapter 5 configuring 2 4 5 7 channel audio 27
- Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 27
- Ously if you want to mute the back panel audio only supported when using an hd front panel audio module refer to chapter 5 configuring 2 4 5 7 channel audio 27
- Some chassis provide a front panel audio module that has separated connectors on each wire 27
- The front panel audio header supports hd audio by default if your chassis provides an ac 97 27
- The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module con nector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 27
- You may connect the audio cable that came with your optical drive to the header 27
- Spdif_in s pdif in header 28
- Spdif_out s pdif out header 28
- 29 hardware installation 29
- Cord from the power outlet to prevent damage to the usb bracket 29
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header prior to installing the usb bracket be sure to turn off your computer and unplug the power 29
- Do not plug the usb bracket cable into the ieee 1394a header prior to installing the ieee 1394a bracket be sure to turn off your computer and unplug the 29
- F_1394 ieee 1394a header 29
- F_usb1 f_usb2 usb headers 29
- Power cord from the power outlet to prevent damage to the ieee 1394a bracket 29
- The header conforms to ieee 1394a specification the ieee 1394a header can provide one ieee 1394a port via an optional ieee 1394a bracket for purchasing the optional ieee 1394a bracket please con tact the local dealer 29
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 29
- Then attach the other end of the cable to the ieee 1394a device ensure that the cable is se curely connected 29
- To connect an ieee 1394a device attach one end of the device cable to your computer and 29
- When the system is in s4 s5 mode only the usb ports routed to the f_usb1 header can sup port the on off charge function 29
- Coma serial port header 30
- Hardware installation 30 30
- Lpt parallel port header 30
- The com header can provide one serial port via an optional com port cable for purchasing the op tional com port cable please contact the local dealer 30
- The lpt header can provide one parallel port via an optional lpt port cable for purchasing the optional lpt port cable please contact the local dealer 30
- Clr_cmos clearing cmos jumper 31
