Cyberpower CPS1000EI [2/2] Functional test

2. DC Input Cable (Red)

Connect to battery positive polarity.

3. Input Circuit Breaker

The circuit breaker provides optimal overload protection.

4. Charger Control*

A. Select “Default” setting for general application. The charge voltage is 13.7V, 27.4V

respectively for CPS1000EI and CPS2000EI.

B. Select “Customized” setting for special battery condition. The charge voltage is 13.3V,

26.6V, respectively for CPS1000EI and CPS2000EI.

*Note: Operate by trained professionals ONLY. Incorrect operation will damage the battery.

5. Input Voltage Range Selector

Input voltage range is defined in specification section. Output voltage is the same as input voltage

in AC mode.

A. Select “Narrow” setting for general electrical appliance such as TUBE LIGHT, ENERGY

SAVING LAMP, TV, JUICER & MIXER etc. It is not suitable for high-power motor or inductive

load, such as the fridge of 1KW, the motor of 800W, AIR COOLER（having risk of rebooting）

and so on. In this mode, the INVERTER operating voltage in AC mode is within 190~260Vac

with the same output voltage. The line sensitivity is higher.

B. Select “Wide” setting to save energy. In this mode the operating range of voltage for the

INVERTER is 100-280Vac. Therefore the output voltage will be the same as the MAINS input

voltage. The INVERTER unit in this mode has a lower sensitivity with a longer transfer time for

switching from AC mode to battery mode in the event of power failure. You can safely connect

and use home appliances which are not sensitive to transfer time limitations such as florescent

tubes, bulbs, TV etc.

6. AC outlet**

The INVERTER provides one outlet for connected equipment to insure temporary uninterrupted

operation during a power failure and against surges and spikes.

**Note: 5 outlet types available, including Schuko, French, UK, India and NEMA, type.

7. AC Inlet

Connect to utility power through the input power cord.

Functional Test

AC Mode

The INVERTER delivers power to the load derived from the utility and maintains proper battery charge.

On-Battery Mode

The INVERTER operates on battery when the utility voltage has fallen outside the limits. Local users are

alerted to this mode of operation by visual and audible indicators. The INVERTER provides power to the

load from the battery and the output voltage of the INVERTER are regulated within a narrow range

1. Switch On

Press the power switch then the status LED will light up.

2. Switch Off

Press again the power switch, the status LED will go off.

3. Cold Start / Start on Battery:

This INVERTER can be turned on even when AC is not present.

Press the power switch then the status LED will light up.

ROUTINE MAINTENANCE AND STORAGE

ROUTINE MAINTENANCE

1. Use dry soft clothes to clean the panel and plastic parts. Do not use any detergent that contains

alcoholic ingredient.

2. Unplug the INVERTER from power inlet if the INVERTER will not operate for long period of time.

STORAGE

1. First turn off your INVERTER and disconnect its power cord from the wall outlet. Disconnect all

cables connected the INVERTER to avoid battery drain.

2. The INVERTER should be stored in a cool dry location.

3. Make sure the battery is fully charged before the INVERTER is stored.

4. For extended storage in moderate climates, the battery should be charged for 12 hours every 3

months by plugging the power cord into the wall receptacle and turning on the main switch. Repeat

it every 2 months in high temperature locations.

DEFINITIONS FOR INDICATORS

Condition Fault

Battery Mode

AC Mode

Alarm

Normal Mode

(Battery is fully charged)

Off Off On Off

Normal Mode

(Battery is charging)

Off Off Normally On but blink

every 5 seconds

Off

Battery Mode

(above low battery voltage)

Off On Off Off

Battery Mode

(under low battery voltage)

Off On Off Beeps every 2

seconds

Off charge mode

(Auto bypass)

Off Off Normally Off but blink

every 5 seconds

Off

Fault On Off Off Beeps

continuously

Overload Blink every

0.5 seconds

Off Off Beeps every 0.5

seconds

TROUBLE SHOOTING

Problem Possible Causes Remedy

No LED display

1. Battery Weak 1. Re-charge battery

2. Battery defective 2. Battery replacement.

3. Power switch is not

pressed

3. Press and hold power

switch.

Mains normal but not works in

AC mode

1. AC Input missing

1. Check AC input

connection.

2. Input protector is effective 2. Reset the input protector.

Alarm buzzer beeps

continuously

Overload

Verify that the load matches

the capability specified in

the specs.

Backup time is shortened

Overload

Remove some non-critical

load.

Battery voltage is too low.

Charge battery for 8 hours

or more.

If any abnormal situations occur that are not listed above, please contact service personnel.

TECHNICAL SPECIFICATIONS

Model CPS1000EI CPS2000EI

Capacity (VA) 1000VA 2000VA

Capacity (Watts) 600W 1200W

Input

Input Voltage Range Wide mode: 100VAC-280VAC

Narrow mode: 190VAC-260VAC

Frequency Range 50/60Hz

Output

On Battery Output

Voltage

Simulated Sine Wave at 220Vac +/-10%

On Battery Output

Frequency

50/60Hz

Overload Protection On Utility: Circuit Breaker, On Battery: Internal Current Limiting

Physical

Total # of INVERTER

Receptacles

(1) Schuko/FR/UK/ India/NEMA/UN

Maximum Dimensions 265mm(L)*250cm(W)*90cm(H)

Weight 1.9 kg / 4.2 Lbs 2.0 kg / 4.4 Lbs

Battery

Lead Acid Battery 12V 24V

Warning Diagnostics

Indicators AC Mode, Power On, Battery mode, Fault

Audible Alarms Low Battery, Overload, Fault

Environmental

Operating Temperature +32°F to 104°F ( 0°C to 40°C )

Operating Relative

Humidity

0 to 90% NON-CONDENSING

Management

Auto-Charger Yes

Auto-Restart Yes

Visit www.cyberpower.com for more product information and the nearest CyberPower local contact for

your region.

in whole or in part without permission is prohibited.
