CUTTING OPERATION

PRELIMINARIES

WARNING: unplug the unit from the power supply before assemble or disassemble piled parts,

single parts, parts of the torch, torch assemblies or cables.

√ Check and follow instructions as foreseen in the paragraphs “Safety and Installation” of the

present instructions manual.

PARTS OF THE TORCH

√ Check the torch for proper assembly. Install proper torch parts for the desired application (refer

to Section called Torch Consumable Parts Selection). NOTE: The power supply will not opera-

te unless the torch shield cup is fully seated against the PIP (Parts in Place) pins in the torch

head.

INPUT POWER

√ Check the power source for proper input voltage.

√ Make sure the power source meets circuit protection and wiring requirements.

√ Plug unit in and close main disconnect switch to supply primary power to the system.

GROUND CABLE

√ Check for a solid ground cable connection to the workpiece.

AUTOMATIC PURGE SYSTEM

√ Place the ON/OFF switch to the ON position. The ON light will icker momentarily as the system

powers up and then stays on. Activate the torch button to initiate gas purge (pre-ow) to will

remove any condensation that may have accumulated in the torch and leads while the system

was shut down. When the gas purge is complete, pilot arc will be initiated.

WARNING

Do not initiate pilot arc during adjustment.

CHECKING AIR QUALITY

√ To check air quality, deactivate the torch (post-ow) and place welding lter lens in front of the

torch. Any oil or moisture in the air will be visible on the lens. DO NOT initiate pilot arc while

checking air quality.
