JetStream Smart Switch
05Introduction
the Speed LED will turn off and the PoE LED will light up. Then the PoE LED will turn off after being on
for 60 seconds and the Speed LED will light up again.
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS
Flashing: The switch works properly.
On or Off: The switch works improperly.
FAN
Green: All the fans work properly.
Yellow: Not all the fans work properly.
PoE Max
(When the PoE LED
is on)
On: The remaining PoE power≤7W.
Flashing: The remaining PoE power keeps≤7W after this LED is on for 2 minutes.
Off: The remaining PoE power
＞
7W.
10/100M or PoE
(When the Speed
LED is on)
Green On: Running at 100Mbps, but no activity.
Green Flashing: Running at 100Mbps and is transmitting or receiving data.
Yellow On: Running at 10Mbps, but no activity.
Yellow Flashing: Running at 10Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for T1500-28PCT.
1000M
Speed or PoE
(When the Speed
LED is on)
Green On: Running at 1000Mbps, but no activity.
Green Flashing: Running at 1000Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100Mbps, but no activity.
Yellow Flashing: Running at 10/100Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000M for T1500-28PCT. Speed or PoE for T1500G-10MPS, 1-24 ports of
T1600G-28PS and 1-48 ports of T1600G-52PS (TL-SG2452P)
10/100M or PoE
Speed or PoE
(When the PoE LED
is on)
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum power.
Yellow On: Overload or short circuit is detected.
Yellow Flashing: Power-on self-test failed.
Off: Not providing PoE power on the port.
Note: 10/100M or PoE for T1500-28PCT. Speed or PoE for T1500G-10MPS, 1-24 ports
of T1600G-28PS and 1-48 ports of T1600G-52PS (TL-SG2452P)
100Base-FX
1000Base-X
SFP1, SFP2
Green On: A 1000Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 10/100Mbps device is linked to the corresponding port, but no activity.
Yellow Flashing: A 10/100Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note:
1000Base-X for 25-28 ports of T1600G-28PS. 100Base-FX/1000Base-X for 49-
52 ports of T1600G-52PS (TL-SG2452P)
. SFP1/SFP2 for T1500G-10MPS.
100Base-FX and 1000Base-X ports don't support 10Mbps device.
