JetStream 8-Port Gigabit Smart PoE Switch with 2 SFP Slots
T1500G-10PS (TL-SG2210P)
Ethernet Ports (1-8)
1. To access the GUI of the switch, open a browser and type the default
management address http://192.168.0.1 in the address eld of the
browser, then press the Enter key.
Note:
To log in to the switch, the IP address
of your PC should be set in the same
subnet as that of the switch. The IP
address is 192.168.0.x (”x” is any
number from 2 to 254). Subnet Mask
is 255.255.255.0. For details, please
refer to Appendix B in the User Guide
on the resource CD.
2. Enter admin for both the User Name
and Password in the lower case
letters. Then click the Login button
or press the Enter key.
3. After a successful login, the main
page will appear as follows, and you
can click the menu on the left side
to congure the corresponding
functions.
Note:
For more details about how to congure the switch, see the User Guide on
the resource CD.
PC
SFP Slots
IP Camera AP IP Phone
PoE Devices
Note:
1. PoE ports can also connect to non-PoE devices, but only transmit data.
2. Maximum PoE power is 15.4W for each PoE port and 53W for all PoE ports.
DC Power Adapter
AC Power Cord
1
2
3
LED Explanation
Installation Guide
Conguration
Connection
On: Power on
O: Power o
Power
Power
SPF1/SFP2
On(Green): Connected to a 1000Mbps
device
On(Yellow): Connected to a 100Mbps
device
Flashing: Transmitting/receiving data
SPF1 SPF2
Flashing: System running normally
On/O: System running abnormally
System
System
On: 46W≤Total power supply<53W
Flashing: Total power supply keeps≥
46W more than 2 minutes
O:
Total power supply<46W
PoE MAX
PoE MAX
PoE Status (port 1-8)
On: Providing PoE power
Flashing: Current-overload/Short-circuit/
Connected to a Non-standard PD/Power
exceeded the user-dened value
O: Not providing PoE Power
PoE Status
Link/Act (port 1-8)
On(Green):
Connected to a 1000Mbps device
On(Yellow): Connected to a 10/100Mbps
device
Flashing: Transmitting/receiving data
Link/Act
Internet
Содержание
- Configuration 1
- Connection 1
- Installation guide 1
- Led explanation 1
- A1 make sure that the cable connectors are firmly plugged into the switch and the device 2
- A1 make sure that this poe device complies with ieee 802 af ieee 802 at 2
- A2 make sure the connected device is turned on and works normally 2
- A2 try another poe port on the switch 2
- A3 pay attention to poe priority if the total power consumption of poe powered devices exceeds 53w a priority will be set among the ports ports with a smaller port number will have higher priority for example port 1 2 and 5 are each consuming 15 w if an additional powered device consuming 12w is connected to port 3 then the switch will cut off power to port 5 because of the overload 2
- A3 try to change the connected device s transmission speed and duplex mode 2
- A4 the cable must be less than 100 meters long 328 feet 2
- Bsmi notice 2
- Cautions 2
- Ce mark warning 2
- Environmental and physical specifications 2
- Explanation of the symbols on the product label 2
- Fcc statement 2
- For technical support and other information please visit http www tp link com support 2
- Frequently asked questions faq 2
- General specifications 2
- Industry canada statement 2
- Make sure the ac power cord is connected to the switch with power source properly 2
- Make sure the power source is on 2
- Make sure the voltage of the power supply meets the requirements of the input voltage of the switch 2
- Please try the following 2
- Q1 the power led is not lit 2
- Q2 why is the link act led not lit while a device is connected to the corresponding port 2
- Q3 why are some ports not supplying power for poe devices 2
- Safety notices 2
- Specifications 2
- The power led should be lit when the power system is working normally if the power led is not lit please check as follows 2
