6-Using the Oscilloscope

4. Right click 1 or 2 red mark area, choose Format. And system will pop up a

warning message, click Yes.

Format the USB disk warning

5. Set File System as FAT32, Allocation unit size 4096. Check "Perform a quick

format" to execute a quick format. Click OK, and then click Yes on the warning

message.

Formatting the USB disk setting

6. Formatting process.
