2.Quick Start

(2) Lift the tilt stand and loosen the screws with a suitable Phillips screwdriver and

remove the battery cover.

(3) Observe the battery polarity indicated inside the battery compartment, Insert the

batteries.

(4) Place the battery cover back in its original position and tighten the screws.

Caution

: To avoid instruments being damage from battery leakage, always remove

the batteries and store them separately if the multimeter is not going to be

used for a long period.

Adjusting the Tilt Stand

Pull the tilt stand outward to its maximum reach (about 85° to the meter body).

Power On

(1) To power ON the multimeter, turn the rotary switch to any other position except

(2) To power OFF the multimeter, turn the rotary switch to the

position.

Sleep Mode

The multimeter automatically enters the sleep mode if the rotary switch is not moved or

a key is not pressed for 30 minutes. (When the Bluetooth is activated, this function is

disabled.)

Pressing or turn the rotary switch will turn the multimeter back to operation

mode from the sleep mode.

One minute before Auto Power-off, the buzzer will beep five times to warn. Before shutoff,

the buzzer will emit a long beep, and then the multimeter will shut off.

Note: In sleep mode, the multimeter will still consume a little po wer. If the multimeter is

not going to be used for a long period, the power should be turned off.

LCD Backlight Control

To view the display in low-light conditions, you can activate the LCD backlight by pressing

for more than 2 seconds. The backlight will last for one minute. To turn off

manually, pressing for more than 2 seconds.
