RIGOL Chapter 3 Remote Control
3-6 DL3000 User’s Guide
resource found is displayed at the right of the window as shown in Figure (b).
Click to add it.
(a)
(b)
Note: If you want to remove the resource, select the resource and then click
to remove it.
4. View the device resource
The searched instrument resource will be under the directory of "RIGOL Online
Resource", as shown in the following figure.
