RIGOL Chapter 2 Front Panel Operation

User’s Guide for DSA800/E Series

2-110

System Settings

System

Set the system parameters.

Language

DSA800/E supports multi-language menu, Chinese and English bulid-in help and

popup messages.

Press this key to select the desired display language.

Reset

Functions include: select the instrument settings to be recalled after the analyzer is

powered on (“Last” or “Preset”); set the preset type (“Factory” or one of “User1” to

“User6”) and save system configuration.

1. Power On

Set the power on setting to “Last” or “Preset”.

 When “Last” is selected, settings before the last power-off would be

recalled automatically at power on.

 When “Preset” is selected, settings defined in Preset Type would be

recalled automatically at power on.

2. Preset Type

Set the preset type to factory (default) or one of User1 to User6.

 When Power On is set to “Preset”, the specified preset type will be

recalled at power on.

 After the instrument starts, press Preset at the front panel under any

operation interface will recall the specified preset type.
