- 60 -GA-8ILFT Series Motherboard
English
Ø For your reference, you can use the following steps to complete the RealTek
8139/8130/8100 Network Driver Installation.
Appendix C: RealTek 8139/8130/8100 Network Driver *
(1)
1.Click "RealTek Network Driver"
item.
(2)
(3)
2.Click "Finish" to restart computer.
(4)
* For GA-8ILFT Only.
