RIGOL
User’s Guide for DS1000B Series
6-1
Chapter 6 Appendixes
Appendix A: DS1000B series Accessories
Standard Accessories
Probe×4 , 1:1 (10:1) Passive Probes
When the switch of probe is toggled to 1X attenuation setting, the probe has
6MHz bandwidth, according with 150V CAT II.
When the switch of probe is set to 10X attenuation setting ,the probe’s
bandwidth equals to the upper limit of the oscilloscope, according with 300V
CAT II.
A Power Cord that fits the standard of destination country.
An USB Cable
A CD-ROM (including User’s Guide an application software)
A Quick Guide
Optional Accessories:
BNC Cable
USB-GPIB Adapter
50Ω Impedance Adapter
DS1000B special convenient soft bag
All accessories (standard and optional) are available by contacting your
local RIGOL office.
