User’s Guide for DS1000B Series

2-15

Figure 2-17 Table 2-7 The Math menu (Page 2/2)

Menu Settings Comments

The multifunctional knob ( ) adjusts

the vertical position of the Math

waveform.

The multifunctional knob ( ) adjusts

the vertical amplitude of the Math

waveform.

Reset

Reset the math waveform to vertical

mid-point.
