RIGOL

User’s Guide for DS1000B series

2-64

1. Disk Information

Press Storage →Disk Mgr. →Disk info to go to the disk information interface.

Figure 2-81 Disk information interface

2. Rename

Press Storage→Disk Mgr.→Rename to go to the following interface.

Figure 2-82

Rename the file
