Feature

This product detects the battery voltage of a vehicle and buffers the output voltage at 12VDC when

sudden drops in the input voltage are detected. Such drops usually happen during engine cranking or

re-start in case of cars with stop/ start function.

The KPX-100B can buffer one CD- Tuner or Mobile Media Station (or similar product) plus a steering

wheel remote control or CAN interface.

Amplifiers and other high current products must under no circumstances be connected to the output of

the KPX-100B.

Specifications

Input Voltage………… 6VDC - -- 13,8VDC

Output Voltage.……… 12 VDC (stabilized)

Output Current:

Average. ………….. 7,5A (@ 8,1VDC)

Max. ………………. 9A (@ 8,1VDC,

t < 3.000 ms)

Bypass. …………… 13A (average)

16A (t < 500ms)

Power Consumption:

Bypass…………….. 0,3mA

Temperature range….. -30°C to +80°C

Weight………………... 68g

Dimensions: W x L x H... 106 x 30 x 71mm
