20
UNI-T
®
UT4000 User Manual
5. Waveform inversion setup
Waveform inversion : The displayed signal is inverted 180 degrees with respect to the
channel ground level. Figure 2-8 shows the non-inverted waveform. Figure 2-9 shows the
inverted waveform.
Figure 2-8 Inversion setup for vertical channel inversion (non-inverted)
Figure 2-9 Inversion setup for vertical channel inversion (inverted)
Non-inverted
Inverted waveform
