- 32 -8S651M-RZ Series Motherboard

English

SYSTEM FAN Fail Warning

Disabled Fan Warning Function Disable. (Default value)

Enabled Fan Warning Function Enable.

Frequency/Voltage Control

CPU Clock Ratio [10X]

Linear Frequency Control [Disabled]

x CPU Clock (MHz) 100

x DRAM Clock (MHz) AUTO

x AGP Clock (MHz) AUTO

x PCI Clock (MHz) AUTO

Frequency/Voltage Control

higf: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Save Default F7: Optimized Defaults

Item Help

Menu Level u

CPU Clock Ratio

This setup option will automatically assign by CPU detection.

For Willamette CPU:

8X~23X default: 14X

For C-Stepping P4:

8X,10X~24X default: 15X

For Nor thwood CPU:

12X~24X default: 16X

The option will display "Locked" and read only if the CPU ratio is not changeable.

Linear Frequency Control

Disabled Disable this function. (Default value)

Enabled Enable this function.

CPU Clock

100~355 Select CPU Clock to 100MHz~355M Hz.

If you use FSB400 Pentium 4 processor, please set "CPU Clock" to 100MHz.If you use FSB533

Pentium 4 processor, please set "CPU Clock" to 133MHz. If you use FSB800 Pentium 4

processor, please set "CPU Clock" to 200M Hz.

Incorrect using it may cause your system broken. For power End-User use only!

DRAM Clock (MHz)

Please set DRAM Clock according to your requirem ent.

If you use DDR200 DRAM module, please set "DRAM Clock(MHz)" to 200. If you use DDR333

DRAM module, please set "DRAM Clock(M Hz)" to 333.

Incorrect using it may cause your system broken. For power End-User use only!
