- 29 - BIOS Setup
English
Power Management Setup
ACPI Suspend Type
S1(POS) Set ACPI suspend type to S1. (Default Value)
S3(STR) Set ACPI suspend type to S3.
Power LED in S1 state
Blinking The Power LED will be blinking during S1 state. (Default value)
Dual/OFF The Power LED will be turned off or change color.
ECP Mode Use DMA
This feature allows you to select Direct Memory Access(DMA) channel if the ECP mode selected.
This option is available only when Parallel Port Mode is set to ECP or ECP+EPP.
1 Set ECP Mode Use DMA to 1.
3 Set ECP Mode Use DMA to 3. (Default value)
Game Port Address
Disabled Disable this function
201 Enable this function and set gameport address to 201. (Default value)
209 Enable this function and set gameport address to 209.
Midi Port Address
Disabled Disable this function. (Default value)
330 Enable this function and set midiport address to 330.
300 Enable this function and set midiport address to 300.
Midi Port IRQ
This option is available when the Midi Port Address is not set to "Disabled."
5 Set midiport IRQ to 5.
10 Set midiport IRQ to 10. (Default value)
ACPI Suspend Type [S1(POS)]
Power LED in S1 state [Blinking]
Soft-Off by PWR-BTTN [Instant-Off]
PME Event Wake Up [Enabled]
ModemRingOn [Enabled]
Resume by Alarm [Disabled]
x Date (of Month) Alarm Everyday
x Time (hh:mm:ss) Alarm 0 : 0 : 0
Power On by Mouse [Disabled]
Power On by Keyboard [Disabled]
x KB Power ON Password Enter
AC BACK Function [Soft-Off]
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Power Management Setup
higf: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level u
[S1]
Set suspend type to
Power On Suspend under
ACPI OS
[S3]
Set suspend type to
Suspend to RAM under
ACPI OS
