Gigabit Unmanaged Switch

Rear Panel

The rear panel of TL-SG1048 is shown as the following figure.

Grounding Terminal

Power Socket

Figure 1-8 Rear Panel of TL-SG1048

The rear panel of TL-SG1024 is shown as the following figure.

Power Socket

Grounding Terminal

Figure 1-9 Rear Panel of TL-SG1024

The rear panel of TL-SG1016 is shown as the following figure.

Power Socket

Grounding Terminal

Figure 1-10 Rear Panel of TL-SG1016

The rear panel of TL-SG1024D is shown as the following figure.

Grounding Terminal

Power Socket

Figure 1-11 Rear Panel of TL-SG1024D
