6
Name Status Indication
On
(green)
The switch is powered on.
Power
Off The switch is powered off.
On
(green)
There is a PoE PD connected to the port,
which supplies power successfully.
Flashing
(green)
The PoE power circuit may be in short or
the power current may be overloaded.
PoE
ports
(port-1~
port-4)
Off
No PD is connected to the corresponding
port，or no power is supplied according to
the power limits of the port.
On
(red)
The power of all the connected PoE ports is
>=50W. No power may be supplied if
additional PDs are connected.
Flashing
(red)
The power of all the connected PoE ports is
>=57W.
PoE
MAX
Off
The power of all the connected PoE ports is
<50W, or there is no PD connected to the
corresponding port.
On
(green)
A valid link is established on the port.
Flashing
(green)
Data transmitting or receiving on
corresponding port.
Link/Act
(port-1~
port-8)
Off
No device is connected to the
corresponding port.
Note
If all PoE PDs power consumption is >= 57W, a priority* will be
arranged among the PoE ports like port-1 = port-2 = port-3 >
