2.2 Power On

The TL-SF1008P switch can be used with DC power supply.

Powering on the switch, it will automatically initialize and its LED

indicators will respond as follows:

1) Firstly, the Power LED indicator will light up.

2) Then, the Link/Act LED indicators will flash momentarily for

one second, which represents a resetting of the system.

If the LED indicators don’t respond as described above, please

check the power supply and its connection.

Identifying External Components

This Chapter describes the front panel, rear panel and LED indi-

cators of the switch.

3.1 Front Panel

Figure 3-1 TL-SF1008P Switch Front Panel

The switch’s LEDs are located on the front panel.
