1.2 Features

¾ Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab,

IEEE 802.3af standards

¾ Data and Power carried over the same cable

¾ Supports optional 5V DC, 9V DC or 12V DC power supply

¾ Supports Plug-and-Play for the devices ， without any

configuration

¾ Elegant appearance with space-saving mini size

Chapter 2 Identifying External Components

Power-mode switch:

You can choose the DC

output of 12V, 9V or 5V

by turning the switch to

the left or right.

Please make sure that the output voltage is

correct, a wrong voltage may destroy the device

which you want to power up.

POWER+DATA IN:

Connect to the PSE

or PoE Injector with

a CAT5 UTP cable.
