Chapter 1 Preface

1.1 Inspection

Please inspect the following items carefully.

1. Package: Check if the package is complete.

2. Bubble wrap: It can protect the product. Please make sure the sticker is firmly

stuck on it.

3. R1-EC7062: Please make sure no damage is shown on its appearance and the

accessories are all attached.

4. Installation Guide: Check if there is an installation guide.

1.2 Model Explanation

（1）

（2）

（3）

（4）

（5）

（6）

（7）

（1）Product Type

R: Remote

（2）Product Category

1: Type 1 - Slim

（3）Product Name

EC: EtherCAT

（4）Module Type

7: Gateway Digital Output Module

（5）Module Subtype 1

0: 3.50 mm Terminal Connector

（6）Module Subtype 2

6: NPN Type / 24 VDC / 0.5 A

（7）Port Number

2: 16 sets

1.3 Using R1-EC7062

This product has to be used with R1-EC5500 of Delta Electronics.
