![Gigabyte GA-8I945GMF-RH [59/80] Part one](/views2/1047847/page59/bg3b.png)
Appendix- 59 -
English
Method 1 : Q-Flash
TM
Utility
Q-Flash
TM
is a BIOS flash utility embedded in Flash ROM. With this utility,
users only have to stay in the BIOS menu when they want to update
BIOS. Q-Flash
TM
allows users to flash BIOS without any utility in
DOS or Windows. Using Q-Flash
TM
indicating no more fooling around with any complicated instructions
and operating system since it is in the BIOS menu.
Please note that because updating BIOS has potential risk, please do it with caution!! We are
sorry that Gigabyte Technology Co., Ltd is not responsible for damages of system because of
incorrect manipulation of updating BIOS to avoid any claims from end-users.
Before You Begin:
Before you start updating BIOS with the Q-Flash
TM
utility, please follow the steps below first.
1. Download the latest BIOS for your motherboard from Gigabyte's website.
2. Extract the BIOS file downloaded and save the BIOS file (the one with model name.Fxx. For
example, 8KNXPU.Fba) to a floppy disk.
3. Reboot your PC and press Del to enter BIOS menu.
The BIOS upgrading guides below are separated into two parts.
If your motherboard has dual-BIOS, please refer to Part One.
If your motherboard has single-BIOS, please refer to Part Two.
Part One:
Updating BIOS with Q-Flash
TM
Utility on Dual BIOS Motherboards.
Some of Gigabyte motherboards are equipped with dual BIOS. In the BIOS menu of the motherboards
supporting Q-Flash and Dual BIOS, the Q-Flash utility and Dual BIOS utility are combined in the same
screen. This section only deals with how to use Q-Flash utility.
In the following sections, we take GA-8KNXP Ultra as the example to guide you how to flash BIOS
from an older version to the latest version. For example, from Fa3 to Fba.
Intel i875P AGPset BIOS for 8KNXP Ultra Fa3
Check System Health OK , VCore = 1.5250
Main Processor : Intel Pentium(R) 4 1.6GHz (133x12)
<CPUID : 0F27 Patch ID : 0027>
Memory Testing : 131072K OK
Memory Frequency 266 MHz in Single Channel
Primary Master : FUJITSU MPE3170AT ED-03-08
Primary Slave : None
Secondary Master : CREATIVEDVD-RM DVD1242E BC101
Secondary Slave : None
Press DEL to enter SETUP / Dual BIOS / Q-Flash / F9 For Xpress Recovery
08/07/2003-i875P-6A79BG03C-00
Award Modular BIOS v6.00PG, An Energy Star Ally
Copyright (C) 1984-2003, Award Software, Inc.
The BIOS file is Fa3
before updating
4-1-3 Flash BIOS Method Introduction
Содержание
482- Lga775 processor motherboard
- Ga 8i945gmf rh
- D pentiu
- User s manual
- Rev 1103 12me 945gmfr 1103r
- Pentiu
- Product manual classification
- Notice
- Copyright
- Table of content
- Ga 8i945gmf rh motherboard layout 6
- Chapter 1 hardware installation 9
- Block diagram 7
- Chapter 2 bios setup 29
- Chapter 3 install drivers 51
- Chapter 4 appendix 55
- Ga 8i945gmf rh motherboard layout
- Ga 8i945gmf rh
- Block diagram
- Installation notices
- Preparing your computer
- Instances of non warranty
- English
- Chapter 1 hardware installation
- 1 considerations prior to installation
- English
- 2 feature summary
- English
- English
- 3 installation of the cpu and heatsink
- 3 1 installation of the cpu
- English
- 3 2 installation of the heatsink
- English
- 4 installation of memory
- English
- Dual channel ddr ii
- English
- 5 install expansion cards
- Mic in
- Line out front speaker out
- Line in
- Lan port
- Ieee 1394 port
- English
- Com a serial port
- 6 i o back panel introduction
- Vga port
- Usb port
- Ps 2 keyboard and ps 2 mouse connector
- Parallel port
- Surround speaker out rear speaker out
- Side speaker out
- English
- Center subwoofer speaker out
- 7 connectors introduction
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connector is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start if you use a 24 pin atx power supply please remove the small cover on the power connector on the motherboard before plugging in the power cord otherwise please do not remove it
- Hardware installation 19
- English
- 2 atx_12v atx power connector
- English
- Cpu_fan
- 4 cpu_fan sys_fan cooler fan power connector
- The fdd connector is used to connect the fdd cable while the other end of the cable connects to the fdd drive the types of fdd drives supported are 360kb 720kb 1 mb 1 4mb and 2 8mb before attaching the fdd cable please take note of the foolproof groove in the fdd connector
- The cooler fan power connector supplies a 12v power voltage via a 3 pin 4 pin only for cpu_fan power connector and possesses a foolproof connection design most coolers are designed with color coded power connector wires a red power connector wireindicates a positive connection and requires a 12v power voltage the black connector wire is the ground wire gnd please remember to connect the power to the cooler to prevent system overheating and failure caution please remember to connect the power to the cpu fan to prevent cpu overheating and failure
- Sys_fan
- Ga 8i945gmf rh motherboard 20
- Fdd floppy connector
- Ide ide connector
- Sataii0 sataii1 sataii2 sataii3 sata 3gb s connector
- Sata 3gb s can provide up to 300mb s transfer rate please refer to the bios setting for the serial ata and install the proper driver in order to work properly
- Hardware installation 21
- English
- An ide device connects to the computer via an ide connector one ide connector can connect to one ide cable and the single ide cable can then connect to two ide devices hard drive or optical drive if you wish to connect two ide devices please set the jumper on one ide device as master and the other as slave for information on settings please refer to the instructions located on the ide device before attaching the ide cable please take note of the foolproof groove in the ide connector
- Please connect the power led pc speaker reset switch and power switch etc of your chassis frontpanel to the f_panel connector according to the pin assignment below
- Ga 8i945gmf rh motherboard 22
- F_panel front panel jumper
- English
- By default the audio driver is configured to support hd audio to connect an ac97 front panel audio module to this connector please refer to the instructions on page 68 about the software settings
- This connector supports either hd high definition or ac97 front panel audio module if you wish to use the front audio function connect the front panel audio module to this connector check the pin assignments carefully while you connect the front panel audio module incorrect connection between the module and connector will make the audio device unable to work or even damage it for optional front panel audio module please contact your chassis manufacturer
- The pwr_led connector is connected with the system power indicator to indicate whether the system is on off it will blink when the system enters suspend mode
- Pwr_led
- Hardware installation 23
- F_audio front audio connector
- English
- Note when the standby power is shut down usb devices example optical mouses will not light on during system power off
- Ga 8i945gmf rh motherboard 24
- For their usb devices during system power off can connect the devices to this connector via the optional front usb cable
- F_ usb green_usb front usb connector
- English
- Connect cd rom or dvd rom audio out to the connector
- Cd_in cd in
- Be careful with the polarity of the front usb connector check the pin assignments carefully while you connect the front usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional front usb cable please contact your local dealer the green_usb connector provides no standby power when system is off and it does not support usb device to wake up from s3 mode users who wish to shut down the standby power
- Comb serial port connector
- Be careful with the polarity of the com connector check the pin assignment carefully while you connect the com cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional com cable please contact your local dealer
- Serial interface standard set by institute of electrical and electronics engineers which has features like high speed highbandwidth and hot plug be careful with the polarity of the ieee1394 connector check the pin assignment carefully while you connect the ieee1394 cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional ieee1394 cable please contact your local dealer
- Hardware installation 25
- F1_1394 f2_1394 ieee 1394 connector
- English
- Spdif_io spdif in out
- English
- Ci chassis intrusion case open
- You may clear the cmos data to its default values by this jumper to clear cmos temporarily short 1 2 pin default doesn t include the shunter to prevent from improper use this jumper
- This connector allows you to connect external devices to use extra function check the pin assignments before you connect the external device cable please contact your nearest dealer for the optional gigabyte external device
- Hardware installation 27
- English
- Clr_cmos clear cmos
- Ga 8i945gmf rh motherboard 28
- English
- Bat battery
- Chapter 2 bios setup
- Status page setup menu option page setup menu
- Main menu
- English
- Control keys
- Pc health status
- Optimized defaults indicates the value of the system parameters which the system would be in best performance configuration
- Load optimized defaults
- To accept or enter the sub menu
- Load fail safe defaults
- This setup page is the system auto detect temperature voltage fan speed
- Integrated peripherals
- This setup page is control cpu clock and frequency ratio
- If you can t find the setting you want please press ctrl f1 to search the advanced option hidden please load optimized defaults in the bios when somehow the system works not stable as usual this action makes the system reset to the default for stability
- This setup page includes all the items of green function features
- Ga 8i945gmf rh motherboard 30
- This setup page includes all the items of award special enhanced features
- Frequency voltage control
- This setup page includes all the items in standard compatible bios
- Fail safe defaults indicates the value of the system parameters which the system would be in safe configuration
- This setup page includes all the configurations of pci pnp isa resources
- English
- Change set or disable password it allows you to limit access to the system and setup or just to setup
- This setup page includes all onboard peripherals
- Advanced bios features
- The main menu for example bios ver f2
- Standard cmos features
- Set supervisor password
- Power management setup
- Pnp pci configuration
- English
- Day the day from 1 to 31 or the maximum allowed in the month
- 1 standard cmos features
- Year the year from 1999 through 2098
- Week the week from sun to sat determined by the bios and is display only
- The time is calculated base on the 24 hour military time clock for example 1 p m is 13 00 00
- Month the month jan through dec
- Ga 8i945gmf rh motherboard 32
- English
- Ide channel 0 master slave
- Halt on
- Floppy 3 mode support for japan area
- English
- Drive a drive b
- Memory
- Extended memory
- English
- Base memory
- 2 advanced bios features
- Setup the system will boot but will not access to setup page if the correct password is not entered at the prompt default value
- Select boot sequence for onboard or add on cards scsi raid etc
- Processor with ht technology
- Pentiu
- Password check
- Note this item will show up when you install a processor which supports this function
- Ls120 select your boot device priority by ls120
- Lan select your boot device priority by lan
- Zip select your boot device priority by zip
- Hard disk select your boot device priority by hard disk
- Usb zip select your boot device priority by usb zip
- Hard disk boot priority
- Usb hdd select your boot device priority by usb hdd
- Floppy select your boot device priority by floppy
- Usb fdd select your boot device priority by usb fdd
- First second third boot device
- Usb cdrom select your boot device priority by usb cdrom
- English
- To exit this menu
- Disabled disabled this function
- System will detect automatically and show up when you install the inte
- Cdrom select your boot device priority by cdrom
- Bios setup 35
- System the system will not boot and will not access to setup page if the correct password is not entered at the prompt
- On chip frame buffer size
- No execute memory protec
- Limit cpuid max to 3
- English
- Cpu thermal monitor 2 tm2
- Cpu hyper threading
- Cpu enhanced halt c1e
- Cpu eist functio
- On chip primary pci ide
- Non combined set on chip sata mode to non combined sata will be simulated to pata mode
- Enhanced set on chip sata mode to enhanced the motherboard allows up to 6 hdds to use
- English
- Enabled enable usb controller default value
- Enabled enable onboard 2nd channel ide port default value
- Enabled enable onboard 1st channel ide port default value
- Disabled disable usb controller
- Disabled disable this function
- Usb controller
- Disabled disable onboard 2nd channel ide port
- This value will auto make by the setting on chip sata mode and pata ide set to if pata ide were set to ch 1 master slave this function will auto set to ch 0 master slave
- This value will auto make by the setting on chip sata mode and pata ide set to if pata ide were set to ch 0 master slave this function will auto set to ch 1 master slave
- Disabled disable onboard 1st channel ide port
- Sata port 1 3 set to
- Ch master slave set pata ide to ch 1 master slave default value
- Sata port 0 2 set to
- Ch master slave set pata ide to ch 0 master slave
- Pata ide set to
- Bios setup 37
- On chip secondary pci ide
- Auto bios will auto detect default value combined set on chip sata mode to combined you can use up to 4 hdds on the motherboard 2 for sata and the other for pata ide
- On chip sata mode
- 3 integrated peripherals
- Onboard serial port 1
- Onboard parallel port
- Onboard lan boot rom
- Onboard h w lan
- Onboard h w 1394
- G keyless port
- English
- Azalia codec
- Usb mouse support
- Usb keyboard support
- Usb 2 controller
- Parallel port mode
- English
- Ecp mode use dma
- Enabled enable pme event wake up default value
- Enabled enable alarm function to power on system if rtc alarm lead to power on is enabled
- Double click double click on ps 2 mouse left button to power on the system
- You can set resume by alarm item to enabled and key in data time to power on system
- Disabled disable this function default value
- Time hh mm ss alarm 0 23 0 59 0 59
- Disabled disable this function
- Soft off by pwr bttn
- Disabled disable power on by ring function
- S3 str set acpi suspend type to s3 str suspend to ram
- Delay 4 sec press power button 4 sec to power off enter suspend if button is pressed less than 4 sec
- S1 pos set acpi suspend type to s1 pos power on suspend default value
- Date of month alarm everyday 1 31
- Resume by alarm
- Acpi suspend type
- Power on by ring
- 4 power management setup
- Power on by mouse
- Pme event wake up
- Instant off press power button then power off instantly default value
- Ga 8i945gmf rh motherboard 40
- English
- Enabled enable power on by ring function default value
- Kb power on password
- English
- Ac back function
- Power on by keyboard
- Pci 2 irq assignment
- Pci 1 irq assignment
- Ga 8i945gmf rh motherboard 42
- English
- Auto auto assign irq to pci 2 default value
- Auto auto assign irq to pci 1 default value
- 5 pnp pci configurations
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 2
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 1
- If the case is closed case opened will show no if the case have been opened case opened will show yes if you want to reset case opened value set reset case open status to enabled and save cmos your computer will restart
- Current cpu system fan speed rpm
- F monitor cpu system temperature at 9
- Cpu system warning temperature
- F monitor cpu system temperature at 8
- Cpu sysem fan fail warning
- F monitor cpu system temperature at 7
- Case opened
- Bios setup 43
- F monitor cpu system temperature at 6
- 6 pc health status
- English
- Enabled fan warning function enable
- Enabled clear case open status at next boot
- Disabled fan warning function disable default value
- Disabled don t reset case open status default value
- Disabled disable this function default value
- Detect system s voltage status automatically
- Detect system cpu temperature automatically
- Detect cpu system fan speed status automatically
- Current voltage v vcore ddrv 3 v 12v
- Reset case open status
- Current system cpu temperature
- System smart fan control
- English
- Cpu smart fan mode
- Cpu smart fan control
- System memory multiplier
- Memory frequency mhz
- English
- Cpu clock ratio
- 7 frequency voltage control
- Selecting this field loads the factory defaults for bios and chipset features which the system automatically detects
- Ga 8i945gmf rh motherboard 46
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance
- English
- 9 load optimized defaults
- 8 load fail safe defaults
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup
- English
- Bios setup 47
- 10 set supervisor user password
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility
- Ga 8i945gmf rh motherboard 48
- English
- 12 exit without saving
- 11 save exit setup
- English
- English
- English
- Chapter 3 install drivers
- 1 install chipset drivers
- 2 software applications
- English
- 3 driver cd information
- English
- 5 contact us
- 4 hardware information
- English
- U plus d p s universal plus dual power system
- S o s system overclock saver
- M i t motherboard intelligent tweaker
- M i b memory intelligent booster 2
- English
- Download center
- Chapter 4 appendix
- C o m corporate online management
- C i a cpu intelligent accelerator 2
- 1 unique software utilities
- User interface overview
- English
- 1 1 easytune 5 introduction
- Xpress recovery2
- System requirements
- How to use the xpress recovery2
- English
- Boot from cd dvd
- 1 2 xpress recovery2 introduction
- Restore
- Remove
- Reboot
- Precautions
- Limitations
- English
- Backup
- The main screen of xpress recovery2
- Utility on dual bios motherboards
- Utility
- Updating bios with q flas
- Part one
- Method 1 q flas
- English
- Before you begin
- 1 3 flash bios method introduction
- Dual bios utility screen
- Dual bios utility bar
- Dual bios
- Utility title
- Contains the names of four tasks blocking a task and pressing enter key on your keyboard to enable execu tion of the task
- Utility
- Contains the names of four actions needed to operate the q flash dual bios utility pressing the buttons mentioned on your keyboards to perform these actions
- The q flash dual bios utility screen consists of the following key components
- Contains the names of eight tasks and two item showing information about the bios rom type blocking a task and pressing enter key on your keyboard to enable execution of the task
- Task menu for q flash utility
- Action bar
- Task menu for dual bios utility
- Task menu for
- Step1 to use q flash utility you must press del in the boot screen to enter bios menu
- Step 2 press f8 button on your keyboard and then y button to enter the dual bios q flash utility
- Q flas
- Ga 8i945gmf rh motherboard 60
- Exploring the q flas
- Entering the q flas
- English
- Appendix 61
- After pressing enter you ll then see the progress of reading the bios file from the floppy disk
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios
- Utility
- Using the q flas
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios
- Reset your system at this
- Press arrow buttons on your keyboard to move the light bar to load main bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk
- Please confirm again you have the correct bios file for your motherboard
- Move to the bios file you want to flash and press enter
- Knxpu fba is listed
- In this example we only download one bios file to the floppy disk so only one bios file
- If you want to save the current bios for backup purpose you can begin step 1 with save main bios to floppy item
- English
- Do not trun off power or
- Bios file in the floppy
- Bios too
- Becomes fab after
- After system reboots you may find the bios version on your boot screen becomes the one you flashed
- You can repeat step 1 to
- Updating
- To flash the backup
- The bios file
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be displayed
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash
- Press any keys to return to the q flash menu when the bios updating procedure is completed
- Please do not take out the floppy disk when it begins flashing bios
- Ga 8i945gmf rh motherboard 62
- English
- Press y on your keyboard to save and exit
- Press y on your keyboard to load defaults
- Press del to enter bios menu after system reboots when you are in bios menu move to load optimized defaults item and press enter to load bios optimized defaults normally the system redetects all devices after bios has been upgraded therefore we highly recommend reloading the bios defaults after bios has been upgraded
- Part two updating bios with q flas
- English
- Appendix 63
- Utility on single bios motherboards
- Utility
- This part guides users of single bios motherboards how to update bios using the q flas
- Select save exit setup item to save the settings to cmos and exit the bios menu system will reboot after you exit the bios menu the procedure is completed
- Please confirm again you have the correct bios file for your motherboard
- Move to the bios file you want to flash and press enter in this example we only download one bios file to the floppy disk so only one bios file 8ge800 f4 is listed
- If you want to save the current bios for backup purpose you can begin step 1 with save bios to floppy item
- Ga 8i945gmf rh motherboard 64
- Utility screen
- Exploring the q flas
- Utility bar
- English
- Utility
- Do not trun off power or reset your system at
- Using the q flas
- Contains the names of three tasks blocking a task and pressing enter key on your keyboard to enable execution of the task
- This stage
- Contains the names of four actions needed to operate the q flash utility pressing the buttons mentioned on your keyboards to perform these actions
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios
- Bios file in the floppy disk
- The q flashbios utility screen consists of the following key components
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios
- Task menu for q flash utility
- Action bar
- Task menu for
- Q flas
- Press arrow buttons on your keyboard to move the light bar to update bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk
- Please do not take out the floppy disk when it begins flashing bios
- Do not trun off power or
- Congratulation you have updated bios successfully
- Appendix 65
- After system reboots you may find the bios version on your boot screen becomes the one you flashed
- The bios file becomes f4 after updating
- Reset your system at this stage
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be shown at the same time
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash
- Press del to enter bios menu after system reboots and load bios fail safe defaults see how to load bios fail safe defaults please kindly refer to step 6 to 7 in part one
- Press any keys to return to the q flash menu when the bios updating procedure is completed
- English
- Utility
- Methods and steps
- Method 2 bio
- English
- English
- Stereo speakers connection and settings
- English
- 1 4 2 4 6 8 channel audio function introduction
- Channel audio setup
- English
- English
- Channel audio setup
- English
- English
- 2 troubleshooting
- English
- English
- English
- English
- English
- English
- English
- Contact us
- Appendix 79
- English
- To submit a technical or non technical sales marketing question please link to http ggts gigabyte com tw then select your language to enter the system
- Gigabyte global service system
- Ga 8i945gmf rh motherboard 80
Похожие устройства
-
Gigabyte B760M D3H DDR4Инструкция пользователя -
Gigabyte GA-880GM-D2HИнструкция по работе -
Gigabyte Z890 EAGLEЭксплуатационная инструкция -
Gigabyte Z890 EAGLE WIFI7Инструкция по применению -
Gigabyte H610M S2HРуководство по использованию -
Gigabyte Z790 AORUS MASTER XРуководство по работе с устройством -
Gigabyte B660M GAMINGИнструкция пользователя -
Gigabyte B550M DS3H ACИнструкция по работе -
Gigabyte GA-Q87TNРуководство по настройке -
Gigabyte GA-H87TNИнструкция по работе -
Gigabyte GA-B85TNРуководство пользователя -
Gigabyte GA-H81TNИнструкция по применению
Узнайте, как безопасно обновить BIOS с помощью утилиты Q-Flash. Следуйте простым шагам для успешного обновления и избегайте возможных рисков.
