- Make sure your skin is clean, entirely dry and
free from grease. Do not use any cream before
you start epilating.
- The optimal hair length for easy epilation is
3-4mm. If the hairs are too short, wait until they
are longer or try to remove the hairs by
repeatedly moving the appliance across the
skin.
Using the appliance
Attaching and detaching heads
1 To attach a head, place it on the handle and
slide it sideways until it locks into place ('click')
(Fig. 4).
2 To detach a head, slide it sideways and lift it off
the handle (Fig. 5).
Attaching and detaching accessories
1 To attach an accessory (caps or combs), simply
snap it onto the head ('click') (Fig. 6).
2 To detach an accessory, grab its front and back
and pull it upwards off the head (Fig. 7).
Switching the appliance on and off
1 Insert the supply unit in the wall socket and
push the small plug into the appliance (Fig. 8).
Make sure you push the small plug completely
into the socket of the appliance. Once you have
plugged it in fully, you hear a click.
2 To switch on the appliance, push the on/off
slide to setting I or setting II (Fig. 9).
3 To switch off the appliance, push the on/off
slide to setting O.
The integrated light goes on automatically to give
you a better view while you use the epilating head
(Fig. 10).
Epilating, shaving and trimming
The appliance is only suitable for dry use. If you
want to use creams or body lotion, apply them
after you have used the appliance.
Slight skin irritation like red skin or red dots may
occur after epilation. This is normal. We advise you
to epilate before you go to bed at night, as any
redness or skin irritation usually disappears
overnight.
Note: The appliance can only be used with cord.
1 Place the appliance on the skin at a 90° angle
(Fig. 11).
2 When you use the appliance with other heads
and accessories than the epilating head, also
make sure that you place them on the skin at a
90° angle.
3 When you use the appliance on sensitive areas,
stretch the skin with your free hand. When you
use the appliance on your underarms, raise
your arm and put your hand on the back of your
head to stretch the skin (Fig. 12).
4 Move the appliance slowly against the direction
of hair growth (Fig. 3).
Note: If you move the appliance over your skin too
fast, you may not obtain a smooth result.
Note: If your hairs are longer than 3-4mm, pretrim
them for easier and more comfortable epilation.
Epilating head
You can use the epilating head to epilate your legs,
underarms and bikini line.
Massage cap
You can attach the massage cap onto the epilating
head to massage the skin and minimize the pulling
sensation of epilation during use.
Senstive area cap
You can attach the sensitive area cap onto the
epilating head for more comfortable epilation of
sensitive areas (e.g. the underarms and bikini line).
Shaving head
You can use the shaving head to shave your legs
and body.
Note: The appliance can be moved in two
directions, for easier shaving of underarms.
Note: Always check the foil before use. If it is
damaged in any way, replace the cutting unit right
away (see 'Replacement').
Comb for shaving head
You can attach the comb onto the shaving head to
trim hairs to a length of 4mm.
Trimming head
You can use the trimming head to trim hard-to-
reach areas in the bikini zone.
Place the trimming head flat onto the skin to trim
(Fig. 13). Place the trimming head perpendicularly
onto the skin for styling and shaping (Fig. 14).
Comb for trimming head
You can attach the comb onto the trimming head
to trim hairs in the bikini area to a length of 4mm
(Fig. 15).
Cleaning and storage
Keep the handle and the supply unit dry (Fig.
2).
1 Remove the head from the handle.
2 If the shaving head is supplied: Grab the two
trimmers of the cutting unit and pull the cutting
unit out of the shaving head (Fig. 16).
3 Use the cleaning brush to brush away any hairs
that have collected on the heads and
accessories (Fig. 17).
Do not clean the foil of the shaving head cutting
unit with the cleaning brush, to avoid damage
to the foil.
4 Rinse the heads, accessories and cutting unit
under the tap (Fig. 18). Shake them firmly to
remove water drops (Fig. 19).
5 Let all parts dry completely.
6 Place the cutting unit back into the shaving
head ('click').
Lubricate trimmer teeth and foil of the cutting
unit with a drop of sewing machine oil every six
months for optimal performance (Fig. 20).
