GA-8I915G-MFD Motherboard - 18 -
English
1-7 Connectors Introduction
1) ATX_12V
2) ATX (Power Connector)
3) CPU_FAN
4) SYS_FAN
5) FDD
6) IDE
7) S_ATA0 / S_ATA1 / S_ATA2 / S_ATA3
8) F_PANEL
9) PWR_LED
10) AZALIA_FP
11) CD_IN
12) F_USB1 / F_USB2
13) F1_1394 / F2_1394
14) IR
15) COMA
16) COMB
17) CLR_CMOS
18) BAT
1
3
5
2
8
11 15
14
18
17
16
12
10
4
7
6
13
7
9
Center/Subwoofer Speaker Out
Connect the Center/Subwoofer speakers to this connector.
Side Speaker Out
Connect the side surround speakers to this connector.
You can use audio software to configure 2-/4-/6-/8-channel audio functioning.
