Содержание
- Ga 8i865gme 775 r 1
- User s manual 1
- Copyright 3
- Notice 3
- Product manual classification 3
- Chapter 1 hardware installation 9 4
- Chapter 2 bios setup 27 4
- Item checklist 6 optional accessories 6 ga 8i865gme 775 rh rev 2 motherboard layout 7 block diagram 8 4
- Table of contents 4
- Chapter 3 drivers installation 47 5
- Chapter 4 appendix 51 5
- Item checklist 6
- Optional accessories 6
- Ga 8i865gme 775 rh 7
- Ga 8i865gme 775 rh rev 2 motherboard layout 7
- Block diagram 8
- 1 considerations prior to installation 9
- Chapter 1 hardware installation 9
- English 9
- Installation notices 9
- Instances of non warranty 9
- Preparing your computer 9
- 2 feature summary 10
- English 10
- English 11
- 3 1 installation of the cpu 12
- 3 installation of the cpu and cpu cooler 12
- English 12
- 3 2 installation of the cpu cooler 13
- English 13
- 4 installation of memory 14
- English 14
- Dual channel memory configuration 15
- English 15
- 5 installation of expansion cards 16
- English 16
- 6 i o back panel introduction 17
- English 17
- Lan port 17
- Line in 17
- Line out 17
- Mic in 17
- Parallel port 17
- Ps 2 keyboard and ps 2 mouse connector 17
- Serial port 17
- Usb port 17
- Vga port 17
- 7 connectors introduction 18
- English 18
- 2 atx_12v atx power connector 19
- English 19
- Hardware installation 19 19
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connec tor is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start 19
- 4 cpu_fan sys_fan cooler fan power connector 20
- An ide device connects to the computer via an ide connector one ide connector can connect to one ide cable and the single ide cable can then connect to two ide devices hard drive or optical drive if you wish to connect two ide devices please set the jumper on one ide device as master and the other as slave for information on settings please refer to the instructions located on the ide device 20
- English 20
- Ga 8i865gme 775 rh rev 2 motherboard 20 20
- Ide1 ide2 ide connector 20
- The cooler fan power connector supplies a 12v power voltage via a 3 pin 4 pin cpu_fan power connector and possesses a foolproof connection design most coolers are designed with color coded power connector wires a red power connector wire indicates a positive connection and requires a 12v power voltage the black connector wire is the ground wire gnd remember to connect the cpu system fan cable to the cpu_fan sys_fan connector to pre vent cpu damage or system hanging caused by overheating 20
- English 21
- Fdd fdd connector 21
- Hardware installation 21 21
- Sata0 sata1 serial ata connector 21
- Serial ata can provide up to 150 mb s transfer rate please refer to the bios setting for the serial ata and install the proper driver in order to work properly 21
- The fdd connector is used to connect the fdd cable while the other end of the cable connects to the fdd drive the types of fdd drives supported are 360 kb 720 kb 1 mb 1 4 mb and 2 8 mb before attaching the fdd cable please take note of the foolproof groove in the fdd connector 21
- English 22
- F_panel front panel connector 22
- Ga 8i865gme 775 rh rev 2 motherboard 22 22
- Please connect the power led pc speaker reset switch and power switch etc of your chassis front panel to the f_panel connector according to the pin assignment below 22
- English 23
- F_audio front audio panel connector 23
- Hardware installation 23 23
- If you want to use front audio connector you must remove 5 6 9 10 jumper in order to utilize the front audio header your chassis must have front audio connector also please make sure the pin assigments on the cable are the same as the pin assigments on the mb header to find out if the chassis you are buying support front audio connector please contact your dealer please note you can have the alternative of using front audio connector or of using rear audio connector to play sound 23
- Pwr_led 23
- The pwr_led connector is connected with the system power indicator to indicate whether the system is on off it will blink when the system enters suspend mode s1 23
- Be careful with the polarity of the front usb connector check the pin assignment carefully while you connect the front usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional front usb cable please contact your local dealer 24
- Cd_in cd in connector 24
- Connect cd rom or dvd rom audio out to the connector 24
- English 24
- F_usb1 f_usb2 front usb connectors 24
- Ga 8i865gme 775 rh rev 2 motherboard 24 24
- Ci chassis intrusion case open 25
- Clr_cmos clear cmos 25
- English 25
- Hardware installation 25 25
- This 2 pin connector allows your system to detect if the chassis cover is removed you can check the case opened status in bios setup 25
- You may clear the cmos data to its default values by this jumper to clear cmos temporarily short pins 1 2 to prevent improper use of this header we do not include a jumper on it 25
- Battery 26
- English 26
- Ga 8i865gme 775 rh rev 2 motherboard 26 26
- Chapter 2 bios setup 27
- Control keys 27
- English 27
- Main menu 27
- Status page setup menu option page setup menu 27
- Boot menu 28
- English 28
- Ga 8i865gme 775 rh rev 2 motherboard 28 28
- If you don t find the settings you want press ctrl f1 to access advanced options 2 select the load optimized defaults item in the bios setup when somehow the system is not stable as usual this action makes the system reset to the default settings for stability 3 the bios setup menus described in this chapter are for reference only and may differ from the exact settings for your motherboard 28
- Select boot sequence for onboard or add on cards device 28
- The main menu for example bios ver dm 28
- To accept or enter the sub menu 28
- To exit this menu 28
- English 29
- 1 standard cmos features 30
- Access mode use this to set the access mode for the hard drive the four options are chs lba large auto default auto 30
- Capacity capacity of currectly installed hard drive 30
- Day the day from 1 to 31 or the maximum allowed in the month 30
- English 30
- Ga 8i865gme 775 rh rev 2 motherboard 30 30
- Ide channel 0 master slave ide channel 1 master slave 30
- Ide channel 2 3 master 30
- Ide hdd auto detection press enter to select this option for automatic device detection extended ide drive you can use one of the two methods auto allows bios to automatically detect ide sata devices during post default none select this if no ide sata devices are used and the system will skip the automatic detection step and allow for faster system start up 30
- Ide hdd auto detection press enter to select this option for automatic device detection ide channel 0 master slave ide channel 1 master slave ide devices setup you can use one of three methods auto allows bios to automatically detect ide sata devices during post default none select this if no ide sata devices are used and the system will skip the automatic detection step and allow for faster system start up manual user can manually input the correct settings 30
- Month the month jan through dec 30
- The time is calculated base on the 24 hour military time clock for example 1 p m is 13 00 00 30
- Week the week from sun to sat determined by the bios and is display only 30
- Year the year from 1999 through 2098 30
- Base memory 31
- Drive a 31
- English 31
- Extended memory 31
- Floppy 3 mode support for japan area 31
- Halt on 31
- Memory 31
- 2 advanced bios features 32
- Cdrom select your boot device priority by cdrom 32
- Disabled disable this function 32
- English 32
- First second third boot device 32
- Floppy select your boot device priority by floppy 32
- Ga 8i865gme 775 rh rev 2 motherboard 32 32
- Hard disk boot priority 32
- Hard disk select your boot device priority by hard disk 32
- Lan select your boot device priority by lan 32
- Ls120 select your boot device priority by ls120 32
- Note this item will show up when you install a processor that supports this function 32
- Password check 32
- Setup the system will boot but access to setup will be denied if the correct password is not entered at the prompt default value 32
- System the system can not boot and can not access to setup page will be denied if the correct password is not entered at the prompt 32
- To exit this menu 32
- Usb cdrom select your boot device priority by usb cdrom 32
- Usb fdd select your boot device priority by usb fdd 32
- Usb hdd select your boot device priority by usb hdd 32
- Usb zip select your boot device priority by usb zip 32
- Zip select your boot device priority by zip 32
- Cpu eist function 33
- Cpu enhanced halt c1e 33
- Cpu hyper threadin 33
- Cpu thermal monitor 2 tm2 33
- English 33
- Init display first 33
- Limit cpuid max to 33
- No execute memory protec 33
- On chip frame buffer size 33
- Virtualization technology 33
- 3 integrated peripherals 34
- Auto when there is no device to be plugged in ide1 or ide2 sata controller will remap to ide controller default value 34
- Disabled disable onboard 1st channel ide port 34
- Disabled disable onboard 2nd channel ide port 34
- Disabled disable onboard seria ata function 34
- Enabled enable onboard 1st channel ide port default value 34
- Enabled enable onboard 2nd channel ide port default value 34
- English 34
- Ga 8i865gme 775 rh rev 2 motherboard 34 34
- Ide pri master set sata controller to compatible mode this mode will remap sata port 0 to ide primary master 34
- Ide pri slave set sata controller to compatible mode this mode will remap sata port 0 to ide primary slave 34
- Ide sec master set sata controller to compatible mode this mode will remap sata port 0 to ide secondary master 34
- Ide sec slave set sata controller to compatible mode this mode will remap sata port 0 to ide secondary slave 34
- Manual set sata mode manually from sata port0 configure as item 34
- On chip primary pci ide 34
- On chip sata 34
- On chip secondary pci ide 34
- Sata port0 configure as 34
- Sata port0 set sata controller to native mode serial ata mode sata port 0 this mode is only supported by windows xp or later default value 34
- Sata port1 set sata controller to native mode serial ata mode sata port 1 this mode is only supported by windows xp or later 34
- Ac97 audio 35
- English 35
- Legacy usb storage detect 35
- Onboard h w lan 35
- Onboard lan boot rom 35
- Onboard serial port 1 35
- Sata port1 configure as 35
- Usb 2 controller 35
- Usb controller 35
- Usb keyboard support 35
- Usb mouse support 35
- Ecp mode use dma 36
- English 36
- Onboard parallel port 36
- Parallel port mode 36
- 4 power management setup 37
- Acpi suspend type 37
- An incoming call via modem can awake the system from any suspend state or an input signal comes from the other client server on the lan can awake the system from any suspend state 37
- Bios setup 37 37
- Blinking in standby mode s1 poer led will blink default value 37
- Delay 4 sec press power button 4 sec to power off enter suspend if button is pressed less than 4 seconds 37
- Disabled disable modem ring on wake on lan function 37
- Disabled disable this function 37
- Dual off in standby mode s1 a if use single color led power led will turn off b if use dual color led power led will turn to another color 37
- Enabled enable modem ring on wake on lan function default value 37
- Enabled enable pme as wake up event default value 37
- English 37
- Instant off press power button then power off instantly default value 37
- Modemringon wakeonlan 37
- Off by power button 37
- Pme event wake up 37
- Power led in s1 state 37
- S1 pos set acpi suspend type to s1 pos power on suspend default value 37
- S3 str set acpi suspend type to s3 str suspend to ram 37
- This feature requires an atx power supply that provides at least 1a on the 5vsb lead 37
- Ac back function 38
- English 38
- Kb power on password 38
- Power on by keyboard 38
- Power on by mouse 38
- Resume by alarm 38
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci1 39
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci2 39
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci3 39
- 5 pnp pci configurations 39
- Auto auto assign irq to pci1 default value 39
- Auto auto assign irq to pci2 default value 39
- Auto auto assign irq to pci3 default value 39
- Bios setup 39 39
- English 39
- Pci1 irq assignment 39
- Pci2 irq assignment 39
- Pci3 irq assignment 39
- 6 pc health status 40
- Case opened 40
- Cpu system fan fail warning 40
- Cpu warning temperature 40
- Current cpu system fan speed rpm 40
- Current cpu temperature 40
- Current voltage v vcore ddr25v 3 v 12v 40
- Detect cpu system fan speed status automatically 40
- Detect cpu temperature automatically 40
- Detect system s voltage status automatically 40
- Disabled disable the fan fail warning function default value 40
- Disabled disable this function default value 40
- Disabled don t reset case open status default value 40
- Enabled clear case open status at next boot 40
- Enabled enable the fan fail warning function 40
- English 40
- F monitor cpu temperature at 6 40
- F monitor cpu temperature at 7 40
- F monitor cpu temperature at 8 40
- F monitor cpu temperature at 9 40
- Ga 8i865gme 775 rh rev 2 motherboard 40 40
- If the case is closed case opened will show no if the case have been opened case opened will show yes if you want to reset case opened value set reset case open status to enabled and save cmos your computer will restart 40
- Reset case open status 40
- Cpu smart fan control 41
- Cpu smart fan mode 41
- English 41
- 355 set cpu host frequency from 100 mhz to 355 mhz if you use a 533 mhz fsb processor set cpu host frequency to 133 mhz if you use an 800 mhz fsb processor set cpu host frequency to 200 mhz incorrect using it may cause your system broken for power end user use only 42
- 7 frequency voltage control 42
- Cpu 1066 mhz fsb 42
- Cpu 1066 mhz fsb default value 42
- Cpu and a agp graphics card 42
- Cpu clock ratio 42
- Cpu host clock control 42
- Cpu host frequency mhz 42
- Cpus with 1066 mhz fsb through overclocking to enable this feature you must install ddr 400 memory module s a cor 42
- Disabled disable cpu host clock control default value 42
- Disabled disable the use of cor 42
- Enable use of cor 42
- Enabled enable cpu host clock control 42
- Enabled enable the use of cor 42
- English 42
- Ga 8i865gme 775 rh rev 2 motherboard 42 42
- Incorrectly using these features may result in system instability or corruption doing a overclock or overvoltage on cpu chipsets and memory modules may result in damages or shortened life expectancy to these components please be aware that the menu items are for power users only 42
- Note this item will show up when you install a processor which supports this function 42
- O c fsb1066 core cpu 42
- Please note that if your system is overclocked and cannot restart please wait 20 secs for automatic system restart or clear the cmos setup data and perform a safe restart 42
- This setup option will automatically assign by cpu detection the option will display locked and read only if the cpu ratio is not changeable 42
- Agp pci fixed 43
- Agp pci frequency mhz 43
- English 43
- Memory frequency for 43
- Memory frequency mhz 43
- 8 load fail safe defaults 44
- 9 load optimized defaults 44
- English 44
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance 44
- Ga 8i865gme 775 rh rev 2 motherboard 44 44
- Selecting this field loads the factory defaults for bios and chipset features which the system automati cally detects 44
- 10 set supervisor user password 45
- Bios setup 45 45
- English 45
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup 45
- 11 save exit setup 46
- 12 exit without saving 46
- English 46
- Ga 8i865gme 775 rh rev 2 motherboard 46 46
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility 46
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility 46
- 1 install chipset drivers 47
- Chapter 3drivers installation 47
- English 47
- 2 software applications 48
- 3 driver cd information 48
- English 48
- 4 hardware information 49
- 5 contact us 49
- English 49
- English 50
- 1 1 easytune 5 introduction 51
- 1 unique software utilities 51
- Chapter 4 appendix 51
- English 51
- 1 2 xpress recovery2 introduction 52
- Boot from cd dvd 52
- English 52
- How to use the xpress recovery2 52
- System requirements 52
- Xpress recovery2 52
- Backup 53
- English 53
- Limitations 53
- Precautions 53
- Reboot 53
- Remove 53
- Restore 53
- The main screen of xpress recovery2 53
- 1 3 flash bios method introduction 54
- Before use 54
- English 54
- Method 1 q flash 54
- Qflash 54
- Updating the bios 54
- Appendix 55 55
- C select the bios file and press enter 55
- Do not turn off or restart the system when the system is reading updating the bios 2 do not remove the floppy disk or hard drive usb drive when the system is updating the bios 55
- English 55
- Make sure again the bios file matches your motherboard model 55
- Press y to load bios defaults 55
- Step 2 the process of system reading the bios file from the floppy disk is displayed on the screen when the message are you sure to update bios appears press enter the bios update will begin and the current process will be displayed 55
- Step 3 when the update process is complete press any key to return to the q flash main menu 55
- Step 4 press esc and then delete to exit q flash and the system will restart as the system reboots you will see the new bios version during post 55
- Step 5 as the system reboots press delete to enter bios setup select load optimized defaults and press enter to load bios defaults system will re detect all peripherals devices after bios update so we recommend that you reload bios defaults 55
- Step 6 select save exit setup and then press y to save settings to cmos and exit bios setup when the system restarts the whole update process is complete 55
- English 56
- Method 2 bio 56
- Methods and steps 56
- Utility 56
- English 57
- 1 4 2 4 6 channel audio function introduction 58
- Channel audio setup 58
- English 58
- Channel analog audio output mode 59
- English 59
- Channel analog audio output mode 60
- English 60
- 2 troubleshooting 61
- English 61
- Contact us 62
- English 62
- Ga 8i865gme 775 rh rev 2 motherboard 62 62
- Appendix 63 63
- English 63
- Gigabyte global service system 63
- To submit a technical or non technical sales marketing question please link to http ggts gigabyte com tw then select your language to enter the system 63
Похожие устройства
- Ballu BFH/C-10 Инструкция по эксплуатации
- Novex NFP-1006 Инструкция по эксплуатации
- Transcend TS8GJFV30 Инструкция по эксплуатации
- Acme GE100 Инструкция по эксплуатации
- Ballu BFH/S-06 Инструкция по эксплуатации
- Acme GE200 Инструкция по эксплуатации
- Acer Z120 Liquid Z2 Duo Black Инструкция по эксплуатации
- Ballu FH-03 Инструкция по эксплуатации
- Beko WMD 24560 R Инструкция по эксплуатации
- Zte V790 Black Инструкция по эксплуатации
- Acme GH200 Инструкция по эксплуатации
- BBK LT3217S Инструкция по эксплуатации
- Ballu FH-04 Инструкция по эксплуатации
- Acme SA100 Инструкция по эксплуатации
- Zte V880G Blade Blue Инструкция по эксплуатации
- Tefal Compact 5322 Инструкция по эксплуатации
- Ballu NSB-150 Инструкция по эксплуатации
- Acme SE100 Инструкция по эксплуатации
- Neff K4624X6 Инструкция по эксплуатации
- Ballu WF-2320 Инструкция по эксплуатации
Скачать
Случайные обсуждения
