20 | English
2 609 932 638 | (4.7.08) Bosch Power Tools
11.04.2008, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Assembly
Battery Charging
f Use only the battery chargers listed on the
accessories page. Only these battery charg-
ers are matched to the lithium ion battery of
your power tool.
Note: The battery is supplied partially charged.
To ensure full capacity of the battery, complete-
ly charge the battery in the battery charger be-
fore using your power tool for the first time.
The lithium ion battery can be charged at any
time without reducing its service life. Interrupt-
ing the charging procedure does not damage the
battery.
The Li-ion battery is protected against deep dis-
charging by the “Electronic Cell Protection
(ECP)”. When the battery is empty, the machine
is switched off by means of a protective circuit:
The inserted tool no longer rotates.
Do not continue to press the
On/Off switch after the ma-
chine has been automatically switched off. The
battery can be damaged.
The battery is equipped with a NTC temperature
control which allows charging only within a tem-
perature range of between 0 °C and 45 °C. A
long battery service life is achieved in this man-
ner.
Observe the notes for disposal.
Removing the Battery
The battery 9 is equipped with two locking lev-
els that should prevent the battery from falling
out when pushing the battery unlocking button
8 unintentionally. As long as the battery is in-
serted in the power tool, it is held in position by
means of a spring.
To remove the battery 9, press the battery un-
locking button 8 and pull the battery out of the
power tool toward the rear. Do not exert any
force.
Replacing/Inserting the Saw Blade
f Before any work on the power tool, remove
the battery.
f When mounting the saw blade, wear protec-
tive gloves. Danger of injury when touching
the saw blade.
f When changing the saw blade, take care
that the saw blade holder is free of material
residue, e. g. wood or metal shavings.
Selecting a Saw Blade
Use only saw blades suitable for the material be-
ing worked.
An overview of recommended saw blades can
be found at the beginning of these operating in-
structions. Use only saw blades with single-nose
shank. The saw blade should not be longer than
required for the intended cut.
Use a thin saw blade for narrow curve cuts.
Inserting the Saw Blade (see figure A)
Press the saw blade 1 firmly into the saw blade
holder 3 until it can clearly be heard to engage.
This causes the locking sleeve 4 to turn by ap-
prox. 90° and locks the saw blade.
If the saw blade 1 is not locked, turn the locking
sleeve 4 approx. 90° in the direction of the ar-
row until it locks in the open position and a
“click” can be heard. Then press the saw blade
1 into the saw blade holder 3 again.
f Check the tight seating of the saw blade. A
loose saw blade can fall out and lead to inju-
ries.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
WARNING
OBJ_BUCH-760-002.book Page 20 Friday, July 4, 2008 11:32 AM
