Options
Options
v
Bend remedy unit
Device for correcting card bend after printing.
v
Magnetic encoder
Device for writing data to a magnetic stripe card.
It can only be installed on a double-sided printer.
v
Contact IC encoder
Device for writing data to a contact IC card.
v
Non-contact IC encoder
Device for writing data to a non-contact IC card.
Before Use
11
