Evolis Primacy CLM [4/40] Screen navigation
![Evolis Primacy CLM [4/40] Screen navigation](/views2/1483995/page4/bg4.png)
COLOR
TOUCHSCREEN
4
UPPER BAR ON THE SCREEN
Lamination
film
Ribbon Cards Cleaning Wi-Fi
The ribbon, cards, and cleaning statuses are permanently displayed in different colors to indicate the printer
status:
• Green: Ready/OK for printing
• Orange: Alert/Warning
• Red: Error - cannot launch or continue print jobs
When the Laminator or Wi-Fi options are not present and detected on your printer, the Wi-Fi and lamination
options will be dark gray.
The significance of the color codes for the Wi-Fi option is different:
• Wi-Fi icon green: Wi-Fi option is present and activated but the printer is not necessarily correctly
connected to the network.
• Wi-Fi icon orange: Wi-Fi option present but not activated.
SCREEN NAVIGATION
The left arrow takes you back to the previous screen.
The right arrow takes you to the next screen.
The return arrow takes you back to the previous menu if there are several screens.
Indicates the number of screens accessible to the user.
When the icon of a button is grayed out, the button is not active. This means you cannot access the
corresponding screen.
