6
General parameters
Parameter Value
Number of poles 1 2 3 4
Overcurrent protection on poles on every pole
Rated operating voltage U
e
, V 230/400 400 400 400
Rated operating DC voltage per 1 pole, max., V 60
Rated frequency, Hz 50
Rated current I
n
, À 10; 16; 20; 25; 32; 35; 40; 50; 63; 80; 100
Rated impulse withstand voltage U
imp
, V 6000
Rated short-circuit breaking capacity I
cn
, À 10000
Mechanical wear-resistance, not less than, ops. 20000
Electrical wear-resistance, not less than, ops. 6000
Max. size of cables attached to contact terminals, mm
2
35
Tightening torque when using a screw-diver, N∙m 2
Possibility to attach connecting buses to contact terminals PIN (pin)
Max. pole weight, kg, max 0,162
Protection degree according to IEC 60529 IP20
Overcurrent tripping
characteristics, type
Release type Test current Non-tripping or tripping time
Ñ, D thermal release
1,13 I
n
t ≤ 1 hour (at I
n
≤ 63 À) – without tripping
t ≤ 2 hours (at I
n
> 63 À) – without tripping
1,45 I
n
t < 1 hour (at I
n
≤ 63 À) – tripping
t < 2 hours (at I
n
> 63 À) – tripping
2,55 I
n
1 s < t < 60 s (at I
n
≤ 32 À) – tripping
1 s < t < 120 s (at I
n
> 32 À) – tripping
Ñ electromagnetic release
5 I
n
t ≤ 0,1 s – without tripping
10 I
n
t < 0,1 s – tripping
D electromagnetic release
10 I
n
t ≤ 0,1 s – without tripping
20 I
n
t < 0,1 s – tripping
Operation mode long-term
Serviceability none repairable
Service life, max., years 15
Guaranteed service life, years (from the date of sale to consumer)** 5
* Time-current operating characteristics at calibration control temperature – 30 °Ñ
(see Figures 1, 2 of Appendix 1).
** Claims concerning MCBs with damaged or open body are not accepted.
