• Fan coil units • Wall mounted unit • FWT
1
4
• Fan coil units • Wall mounted unit • FWT
10
4 Capacity tables
4 - 3 Heating capacity tables
Air temperature (°C DB - °C WB) 20
Water temperature (Entering °C - Leaving °C) 50 - 45 60 - 50 70 - 60
Model
Air Flow
m
3
/HR
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWT02AT
467 3.20 0.55 74.08 2.90 0.25 18.37 3.31 0.28 21.97
382 2.85 0.49 60.34 2.49 0.21 14.45 2.86 0.25 17.34
297 2.48 0.42 46.88 2.05 0.18 10.78 2.38 0.20 12.92
FWT03AT
510 3.98 0.68 96.36 3.77 0.32 33.23 4.25 0.37 37.69
425 3.46 0.59 79.28 3.18 0.27 26.41 3.61 0.31 30.21
340 2.78 0.48 58.51 2.41 0.21 18.11 2.76 0.24 20.93
FWT04AT
586 4.31 0.74 92.26 3.99 0.34 29.29 4.53 0.39 33.76
484 3.59 0.62 70.51 3.16 0.27 21.01 3.62 0.31 24.51
374 3.00 0.51 54.35 2.50 0.22 15.08 2.88 0.25 17.75
FWT05AT
1070 6.50 1.11 96.71 5.58 0.48 20.07 6.47 0.56 25.28
833 5.40 0.92 68.73 4.21 0.36 12.14 4.98 0.43 15.77
748 4.90 0.84 57.56 3.62 0.31 9.27 4.31 0.37 12.19
FWT06AT
1121 7.21 1.24 124.02 6.19 0.53 25.64 7.20 0.62 32.48
985 6.57 1.13 104.58 5.39 0.46 20.02 6.36 0.55 25.95
799 5.71 0.98 80.76 4.25 0.37 13.08 5.13 0.44 17.62
Air temperature (°C DB - °C WB) 22
Water temperature (Entering °C - Leaving °C) 50 - 45 60 - 50 70 - 60
Model
Air Flow
m
3
/HR
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
Heating
capacity
kW
Water
flow
m
3
/hr
Water
pressure
drop
kPa
FWT02AT
467 2.98 0.51 65.12 2.69 0.23 16.30 3.13 0.27 19.99
382 2.66 0.46 53.06 2.30 0.20 12.81 2.70 0.23 15.75
297 2.29 0.39 41.06 1.89 0.16 9.59 2.23 0.19 11.73
FWT03AT
510 3.70 0.63 87.15 3.52 0.30 30.30 4.03 0.35 35.10
425 3.23 0.55 71.85 2.96 0.25 23.98 3.42 0.29 28.03
340 2.58 0.44 52.81 2.24 0.19 16.37 2.60 0.22 19.33
FWT04AT
586 4.01 0.69 83.01 3.72 0.32 26.47 4.29 0.37 31.23
484 3.34 0.57 63.43 2.93 0.25 18.87 3.41 0.29 22.54
374 2.78 0.48 48.63 2.32 0.20 13.49 2.71 0.23 16.26
FWT05AT
1070 6.04 1.03 84.40 5.12 0.44 17.19 6.07 0.52 22.52
833 5.00 0.86 59.74 3.83 0.33 10.24 4.63 0.40 13.86
748 4.52 0.77 49.74 3.28 0.28 7.78 4.00 0.34 10.65
FWT06AT
1121 6.68 1.14 107.61 5.66 0.49 21.82 6.75 0.58 28.89
985 6.10 1.05 91.14 4.89 0.42 16.80 5.93 0.51 22.86
799 5.29 0.91 70.16 3.81 0.33 10.75 4.74 0.41 15.26
Heating capacities FWT (2 pipe)
