V1512 Guitar Amplifier

V1512 TECHNICAL SPECIFICATIONS:

OUTPUT POWER RATING 15 Watts RMS @ 5 % THD, 16 ohm load, 120 VAC

SIGNAL TO NOISE RATIO 65dB Typical

GAIN 98 dB

TREBLE 8dB range @ 10 kHz

MID 9dB range @ 700 Hz

BASS 12dB range @ 60 Hz

SPEAKER SPECS 12”, 60w, 16 ohm, 1.75” voice coil diameter, 38oz. magnet

PREAMP TUBES (3) 12AX7A

POWER AMP TUBES (2) EL84

POWER REQUIREMENTS 120 VAC, 60 Hz, 70VA

100/115 VAC, 50/60 Hz, 70VA

230 VAC, 50/60 Hz, 70VA

SIZE AND WEIGHT 18-1/2” W x 16-1/2” H x 9-1/2” D, 38 lbs.

The V1512 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.

Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.

Specifications and information in this manual are subject to change without notice.
