1507/1503
Users Manual
22
Earth-bond Resistance Measurement
Range Resolution
Accuracy
1
+
(% of Rdg + Digits)
20.00 0.01
200.0 0.1
2000 1
20.00 k 0.01 k
+
(1.5 % + 3)
1. Accuracies apply from 0 to 100% of range.
Overload Protection ............................................2 V rms or dc
Open Circuit Test Voltage...................................> 4.0 V, < 8 V
Short Circuit Current ...........................................> 200.0 mA
Insulation Specifications
Measurement Range...........................................0.01 M to 10 G model 1507, 0.01 M to 2000 M model 1503
Test Voltages ......................................................50, 100, 250, 500, 1000 V model 1507, 500 and 1000 V model 1503
Test Voltage Accuracy ........................................+ 20 %, - 0 %
Short-Circuit Test Current ...................................1 mA nominal
Auto Discharge....................................................Discharge time <0.5 second for C = 1 µF or less
Live Circuit Detection: .........................................Inhibit test if terminal voltage > 30 V prior to initialization of test.
Maximum Capacitive Load..................................Operable with up to 1 µF load.
