Crown International
1718 W. Mishawka Rd.
Elkhart, IN 46517-9439
TEL: 574-294-8200
FAX: 574-294-8FAX
www.crownaudio.com
Amplifi er Specifi cations
(For more detail, refer to the CTs
multichannel amplifi er datasheet
)
Minimum Guaranteed Power: See power
charts at right.
Frequency Response (at 1 watt, 20 Hz - 20
kHz): ±0.5 dB.
Phase Response (at 1 watt, 10 Hz - 20 kHz):
±35°.
Signal to Noise Ratio below rated power (20
Hz to 20 kHz): 100 dB unweighted.
Total Harmonic Distortion (THD) at 1 watt,
from 20 Hz to 20 kHz: < 0.05%.
Intermodulation Distortion (IMD) 60 Hz and 7
kHz at 4:1, from 163 milliwatts to full band-
width power: < 0.05% (typical).
Damping Factor: 10 Hz to 400 Hz: >180.
Crosstalk (below rated power, 20 Hz to 1
kHz): > 80 dB.
Common Mode Rejection (CMR) (20 Hz to 1
kHz): > 50 dB.
DC Output Offset (shorted input): < ±5 mV.
Input Impedance (nominal): 20 kilohms bal-
anced, 10 kilohms unbalanced.
Maximum Input Level (before input compres-
sion): + 20 dBu.
Load Impedance: (Note: Safe with all types of
loads)
Stereo: 4/8 and 25 ohms (70V)
Bridge Mono: 8/16 and 50 ohms (100V)
Voltage Gain (at maximum level setting),
1.4V sensitivity,
4/8 Ohm Operation: 20:1 (26 dB);
70V Operation: 50:1 (34 dB)
100V Operation: 71.4:1 (37 dB)
Required AC Mains: 120V 60 Hz,
220/230/240V/50 Hz.
Power Draw at Idle (120VAC mains, all chan-
nels in 4/8 ohm mode): 58W.
Power Draw at Idle (120VAC mains, all chan-
nels in 70V mode): 77W.
Cooling: Continuously variable speed forced air,
front-to-back airfl ow.
Dimensions (Width, Height, Depth):
CTs 4200USP/CN: 19 in. (48.3 cm) W x 3.5
in. (8.9 cm) H x 16.25 in. (41.3 cm) D.
CTs 8200USP/CN: 19 in. (48.3 cm) W x 5.25
in. (13.3 cm) H x 16.25 in. (41.3 cm) D.
Front Panel Indicators
Bridge mode
Ready
Signal
Clip
Thermal
Fault
Data
Power
Front Panel Controls
Power switch
Back Panel Controls
Channel level controls
Dual/bridge-mono mode switch
Back Panel Connectors
Output Connectors: One four-pole terminal
strip for every two channels with touch-proof
cover. Accepts up to 10 AWG terminal forks.
Input Connectors: Removable Phoenix-style
barrier connectors for balanced input. Also can
be used as a CobraNet input or a backup for
CobraNet.
Protection Systems
Thermal Level Control
Fault Isolation Topology
Fault
Highpass fi lter
AC under/over voltage protection
Power fuse
Inrush limiting
Variable speed fan
4-ohm (per ch.)
8-ohm (per ch.)
70V (per ch.)
1 kHz
CTs 8200USP/CN
20 Hz–20 kHz
Dual
8 Channels Driven
200W
160W
200W
175W
155W
185W
*
*
4-ohm (per ch.)
8-ohm (per ch.)
70V (per ch.)
1 kHz 20 Hz–20 kHz1 Channel Driven
270W
220W
250W
230W
220W
230W
8-ohm (per ch. pair)
16-ohm (per ch. pair)
100V (per ch. pair)
1 kHz 20 Hz–20 kHz
Bridge-Mono
4 Channel-Pairs Driven
400W
320W
200W
350W
310W
185W
*
*
8-ohm (per ch. pair)
16-ohm (per ch. pair)
100V (per ch. pair)
1 kHz 20 Hz–20 kHz1 Channel-Pair Driven
540W
440W
250W
460W
440W
230W
Maximum Average Power
in watts with 0.1% THD.
*
Constant Voltage full bandwidth power ratings support
100Hz - 20kHz due to automatic High-Pass Filters.
4-ohm (per ch.)
8-ohm (per ch.)
70V (per ch.)
1 kHz
CTs 4200USP/CN
20 Hz–20 kHz
Dual
4 Channels Driven
260W
180W
220W
215W
190W
220W
*
*
4-ohm (per ch.)
8-ohm (per ch.)
70V (per ch.)
1 kHz 20 Hz–20 kHz1 Channel Driven
270W
220W
250W
225W
210W
245W
8-ohm (per ch. pair)
16-ohm (per ch. pair)
100V (per ch. pair)
1 kHz 20 Hz–20 kHz
Bridge-Mono
2 Channel-Pairs Driven
520W
400W
220W
430W
380W
220W
*
*
8-ohm (per ch. pair)
16-ohm (per ch. pair)
100V (per ch. pair)
1 kHz 20 Hz–20 kHz1 Channel-Pair Driven
560W
440W
250W
450W
420W
245W
Maximum Average Power
in watts with 0.1% THD.
*
Constant Voltage full bandwidth power ratings support
100Hz - 20kHz due to automatic High-Pass Filters.
2/08
Crown’s Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for every new Crown amplifi er—
an unsurpassed industry standard. With this unprecedented No-Fault protection, your new Crown
amplifi er is warranted to meet or exceed original specifi cations for the fi rst three years of owner-
ship. During this time, if your unit fails, or does not perform to original specifi cations, it will be
repaired or replaced at our expense. About the only things not covered by this warranty are those
losses normally covered by insurance and those cuased by intentional abuse. And the coverage is
transferable, should you sell your amplifi er.
See your authorized Crown dealer for full warranty disclosure and details. For customers outside
of the USA, please contact your authorized Crown distributor for warranty information or call
574-294-8200.
Specifi cations subject to change without prior notice. Latest
information available at www.crownaudio.com and
iqaudiosystems.com.
Crown and Crown Audio are registered trademarks; PIP is a
trademark of Crown International. HiQnet and System Archi-
tect are trademarks of Harman International Industries, Inc.
Other trademarks are the property of their respective owners.
Printed in U.S.A.
© 2008 Crown Audio
®
, Inc.
139279-2
CTs 4200USP/CN
CTs 8200USP/CN
