Zkteco ES-854N11H [45/49] Manual port mapping

The default access port of Embedded IPC contains HTTP port 80 and TCP port 8000. If the port has been

occupied by other LAN equipment, please modify the default port number to an unuserd port number at

【network transmission capacity, ports, multicast etc.】.

The third step

Enter the Router management interface; detect the port if there is already a Port mapping. If there is, it shows

UPnP setting’s finished.

The forth step

Input the IP address in IE, and add port number of the Embedded IPC, for example: 155.157.12.227:81. If you

want to enter by the Client Software, use the TCP port offered by the outer net.

Note: if there are a few embedded IPCs need to set the UPnP function, in order to avoid IP conflict, set the

ports of embedded IPC into different ports numbers. Otherwise, it will choose the embedded IPC port set

preceded as the first choice.

5.2.2 Manual Port Mapping

The first step

Connect the Embedded IPC to the Router, set the static IP.

The second step

distributed by the Embedded IPC, and set the rule of port mapping, add HTTP and TCP port into mapping list.

Default access ports of Embedded IPC include HTTP port 80 and TCP port 8000, if the ports are occupied by

other LAN devices, please modify the default port of the Embedded IPC into other vacant ports at 【network

transmission capacity, ports, multicast etc.】.

The third step

Input the public net IP address in the IE, and add the port number of the Embedded IPC you want to access after

the IP, for example: http://155.157.12.227:81. If you want to access by Client Software, you can use the outer net

TCP port directly.

Notice: for detail configuration setting, please refer to the user manual of Router.

5.3 NTP Function
