Golden Wheel CSA-2604-32R2/S23-1,5 [4/55] Golden wheel

Golden Wheel CSA-2604-32R2/S23-1,5 [4/55] Golden wheel
零件号码 零件名称
Name of Parts
件数 备注 零件号码 零件名称
Name of Parts
件数 备注
Q'TY
Remarks Parts No. QTY Remarks
EP1015-2A
銘板 ----------------
-
NAME PLATE --------------------------
-
1 XA300015
棉蕊 ------
-
OIL WICK -------------
1
WARN000108
車頭貼紙 ----------
MARK --------------------------------
-
1 XA300120
棉蕊 ------
-
OIL WICK -------------
1
ES0108-0A
导線管 -------------
PIPE --------------------------------
-
2 XB400038
油棉 ------
-
FELT -----------------
1
ES0109-0A
油管 ----------------
-
PIN ---------------------------------
-
1 XB400040
油棉 ------
-
FELT -----------------
1
ES0111-0A
托架 ----------------
-
BRACKET ASSEMBLY --------------------
-
1 XP400040
油管 ------
-
TUBE -----------------
1
ES0113-0A
支柱 ----------------
-
BED PIN -----------------------------
-
4 YA070100
平行銷 ---
-
PIN ------------------
1
ES0116-0A
油指示貼紙--------
-
OIL MARK ----------------------------
-
1 YD050010
彈簧銷 ---
-
PIN ------------------
1
ES0318-0A
擋板 ----------------
-
LATCH -------------------------------
-
1 YD050014
彈簧銷 ---
-
PIN ------------------
1
ES0320-0A
油壺蓋板 ----------
PLATE -------------------------------
-
1 YD050018
彈簧銷 ---
-
PIN ------------------
1
ESTA261401
0
机型銘板 ----------
NAME PLATE --------------------------
-
1 ZMB03507
螺絲 ------
-
SCREW (M3.5-0.6x4.5) -
1
WARN000500
貼紙 ----------------
-
MARK --------------------------------
-
1 ZMC04007
螺絲 ------
-
SCREW (M4-0.7x7) -----
2
ES1223-0A
針板架(前)--------
-
BRACKET (FRONT) ---------------------
-
1 ZMC04010
螺絲 ------
-
SCREW (M4-0.7x7.5) ---
2
ES1225-0A
緩衝墊 -------------
CUSHION RUBBER ----------------------
-
2 ZMH04001
螺絲 ------
-
SCREW (M4-0.7x4) -----
1
ES1226-0A
針板架(後)--------
-
BRACKET (REAR) ----------------------
-
1 ZMJ06015
螺絲 ------
-
SCREW (M6-1.0x25) ----
2
ES1903-0A
油封蓋 -------------
PLUG --------------------------------
-
1 ZMQ04006
螺絲 ------
-
SCREW (M4-0.7x8) -----
5
ES2220-0C
管夾 ----------------
-
CLAMP -------------------------------
-
2 ZMQ04012
螺絲 ------
-
SCREW (M4-0.7x12) ----
4
ES2317-0A
供油管 -------------
PIPE --------------------------------
-
1
ES2319-0
A
止栓 ----------------
-
PLUG --------------------------------
-
1
ES2341-0
A
油位計 -------------
OIL LEVER GAUGE ---------------------
-
1
ES2401-0
A
矽膠油杯 ----------
SILICONE OIL RESERVOIR---------------
-
1
ES2402-0
A
蓋子 ----------------
-
COVER -------------------------------
-
1
ES2406-0
A
系案內 -------------
THREAD GUIDE ------------------------
-
1
ES2409-0
A
矽膠油壺 ----------
SILICONE OIL RESERVOIR---------------
-
1
ES2410-0A
油壺蓋 -------------
COVER -------------------------------
-
1
ES2416-0A
針冷卻器 ----------
NEEDLE THREAD LUBRICATOR-------------
-
1
ES2420-0A
大頭針 -------------
PIN ---------------------------------
-
1
ES6005-0A
針受(前) ----------
NEEDLE GUARD (FRONT) ----------------
-
1
KS0913-0A
接头 ----------------
-
CONNECTING --------------------------
-
2
OBM00040
鋼珠 ----------------
-
PLUG --------------------------------
-
1
WA040014
平墊圈 ------------
-
WASHER -----------------------------
1
1. CSA-2600 本体机构（1） MACHINE BED FRAME（1）
Parts No.
3
