ENGLISH
6
Connecting the external antenna
Connect one end of the antenna adapter to the
external antenna jack on your TV-set and the
other end to the external antenna.
Connecting audio/video adapter
• Audio/video input (AV/IN)
Connect the external video cable to the
corresponding jack (yellow) of your audio/
video adapter. In the same way connect
audio cables to the corresponding jacks of
the audio/video adapter (left channel – to
the white jack, right channel – to the red
jack). Then connect the audio/video adapter
to the AV/IN jack of your TV-set. (Picture 2)
• Audio/video output (AV/OUT)
Connect the external video cable to the
corresponding jack (yellow) of your audio/
video adapter. In the same way, connect
audio cables to the corresponding jacks of
the audio/video adapter (left channel – to
the white jack, right channel – to the red
jack). Then connect the audio/video adapter
to the AV/OUT jack of your TV-set (only in
the USB/CARD mode). (Picture )
ON-SCREEN MENU
In the TV/Video mode press the MENU button to
display the following items: PICTURE, OPTION,
CLOCK, SYSTEM, and PRESET.
Note: In the Video mode the PRESET item is
absent.
Use the CH+▲/CH-▼buttons to select one of
the following items: contrast, brightness, color,
and sharp. Use the VOL+►/ VOL- ◄ buttons to
adjust the value.
OPTION
Use the CH+▲/CH-▼ buttons to select one of
the following items: Language, calendar, game.
LANGUAGE
Use the VOL+►/ VOL-◄- buttons to select one
of the following languages of the on-screen
menu: German, French, Spanish, Italian or
Russian etc.
CALENDAR
Use the CH+▲/CH-▼buttons to set the year
and the VOL+►/ VOL- ◄ buttons to set the
month.
GAME
Press the VOL+►/ VOL- ◄ buttons to start a
game. To move the object to the left use the
VOL- / ◄ button, to the right – the VOL+ / ►
button, to quick move down – the CH- / ▼
button, to turn – the CH+ / ▲ button. To exit
the game and return to the previous mode (TV/
Video) press the POWER button.
Note: We recommend switching to the Video
mode before starting a game.
CLOCK
Use the CH+▲/CH-▼buttons to select one of
the following items: TIME, ON-TIME, OFF-TIME,
ATTENTION (the corresponding title will appear
at the preset time), BESPOKE TIME (switching
to the preset program at the preset time),
POSITION.
Use the VOL- ◄ buttons to set hours and the
VOL+►/ - buttons to set minutes.
SYSTEM
Use the CH+▲/CH-▼buttons to select one of
the following items: COLOR SYSTEM, SOUND
SYSTEM, BLUE BACKGROUND, VERTICAL,
HORIZONTAL
Color system
Use the VOL+► buttons to select one of the
following systems: АВТО/PAL/SECAM.
The recommended value is AUTO.
Note: In the Video mode you can also select
NTSC
Sound system
Use the VOL+► buttons to select one of the
following systems: BG 5.5M, I 6.0M, DK 6.5M
Note: Set the sound system of your region (for
Russia – DK 6.5M).
If the sound is absent or the noise appears
check whether the sound system is properly set.
Blue background
Use the VOL+► / VOL- ◄ buttons to switch on/
off blue color when the signal is absent.
Vertical
Use the VOL+► / VOL- ◄ buttons to vertically
display the current picture. To cancel the
vertical mode, press the buttons once again.
