1630
Users Manual
2
Contacting Fluke
To contact Fluke, call one of the following telephone numbers:
USA: 1-888-44-FLUKE
Canada: 1-800-363-FLUKE
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
USA Service: 1-888-99-FLUKE (1-888-993-5853)
Or, visit Fluke's Web site at www.fluke.com
To register your product, visit register.fluke.com
Safety Information
XWRead First: Safety Information
To ensure safe operation and service of the 1630 Earth
Ground Clamp, follow these instructions:
• Read the operating instructions before use and follow
all safety instructions.
• Use the Clamp only as specified in the operating
instructions, otherwise the Clamp’s safety features
may not protect you.
• Adhere to local and national safety codes. Individual
protective equipment must be used to prevent shock
and arc blast injury where hazardous live conductors
are exposed.
• Before each use, inspect the Clamp. Look for cracks or
missing portions of the Clamp housing or output cable
insulation. Also look for loose or weakened
components. Pay particular attention to the insulation
surrounding the jaws.
• Never use the Clamp on a circuit with voltages higher
than 600 V CAT II or 300 V CAT III.
