Advanced Configuration

Linksys WES610N/WET610N

WPA2

Network Name (SSID) The name of the network you selected is automatically

displayed.

Security Mode WPA2 Personal is automatically displayed.

Encryption WPA2 supports two encryption methods, TKIP and AES, with

dynamic encryption keys. Select the encryption method, AES or TKIP or AES.

Passphrase Enter the key shared by the bridge and wireless router or access

point. It must have 8-63 characters.

Click Refresh to update the on-screen information.

After you have entered the security settings, click Connect.

WEP

Network Name (SSID) The name of the network you selected is automatically

displayed.

Security Mode WEP is automatically displayed.

Encryption Select a level of WEP encryption, 40/64 bits (10 hex digits) or

104/128 bits (26 hex digits).

Key 1 Enter the WEP key of your network.

Tx Key Key 1 is the transmit key used by the bridge.

Authentication The default is Auto, which allows either Open system or Shared

key authentication to be used. Select Open to use open system authentication;

the sender and recipient do not use a WEP key for authentication. Select

Shared to use shared key authentication; the sender and recipient use a WEP

key for authentication.

Click Refresh to update the on-screen information.

After you have entered the security settings, click Connect.

Wireless > WMM®

Configure the Wireless MultiMedia (WMM) settings. WMM prioritizes packets

depending on their respective access mode (traffic type): Background, Best

Effort, Video, or Voice. These settings should only be adjusted by an expert

administrator as incorrect settings can reduce wireless performance.

NOTE

The settings on the WMM screen are designed for advanced users

only.
