6
1. TECHNICAL CHARACTERISTICS
AS182K
Power max..............................................1200 W
Cooling.................................................by-pass
Air delivery............................................170 m
3
/h
Water column vacuum...................2200/mm H
2
O
Container capacity.......................................27 l
Remote control socket.......................1500 W max
Weight......................................................8,2 Kg
AS282K
Power max..............................................1200 W
Cooling.................................................by-pass
Air delivery.............................................170 m
3
/h
Water column vacuum....................2200/mm H
2
O
Container capacity........................................72 l
Remote control socket.......................1500 W max
Weight.......................................................22 Kg
2. DESCRIPTIÓN
A - Polyester filter to set into the tank to pick up
dust, and to remove for liquid suction.
B - Filtering cartridge for very fine dust. To be removed
for liquid suction.
C - Suction inlet
D - The "Y" coupling
E - Flexible hose.
G - Outlet for electric tool.
H - Switch.
I - Float: its purpose is to avoid that liquid may goes
inside motor block during suction.
J - Motor block.
K - Hooks for tightening of motor block to tank.
P - Tank.
In order to keep in good efficiency the
machine it is useful to clean the filters
after each utilization.
3. OPTIONAL ACCESSORIES
(pag. 22 and 23)
8246233 Aspirator kit
8299160 Paper filter bag for AS182K
8299161 Paper filter bag for AS282K
FITTING THE DUST BAG
Only use the dust bag with all the filters on their place.
The bag collects all the dust in conditions of hy-
giene.
If sucked in along with the dust, sharp or wet items
could damage the dust bag.
Change the bag when it has filled to two thirds
with dust.
The bag cannot be reused. It must always be chan-
ged.
4. DRY SUCTION / OPERATING INSTRUCTIONS
- Insert the filters A and B (Fig. 1 and 3).
- If a paper bag is provided, insert it in the tank on
the deflector.
- Assembly the head on tank and block it by hooks
K, (Fig. 1).
- Connect the flexible E hose to the inlet C (Fig. 1).
- Connect the plug to a power socket and turn switch
H (Fig. 2), to position I (Fig. 2)
5. LIQUID SUCTION / OPERATING
INSTRUCIONS
- Remove the filters A and B (Fig. 1 and 3)
- Assembly the head on tank and block it by hooks
K (Fig. 1).
- Connect the flexible E hose to the inlet C (Fig. 1).
- Connect the plug to a power socket and turn switch
H (Fig. 2), to position I (Fig. 2)
If you wish to use the machine for dust collection
again, the filters must be replaced in their original
positions.
Never use the aspirator for decanting
flammable liquids.
If any liquid or foam leaks out of the
appliance, switch off the electrical
supply emmediately.
6. USE WITH POWER TOOLS
Before using the aspirator ensure (Fig. 1):
- That the filter A, is correctly inserted inside the
aspirator. If you use a paper dust bag check that it
is correctly fitted.
- That the supplementary filter B is correctly inserted
in the upper part of the body.
Above nozzle C connect in the following order:
1. The "Y" coupling (D)
2. The flexible tube (E)
3. The power tool
Connect the plug of the tool to the supplementary
socket G (Fig. 2) on the upper part of the aspirator
head.
