Vacuum cleaner ASM582T (Ref. 8200500)
Technical information
Explosion drawing and parts list
DP 110130A00
(*) Parts not mounted in the current version
Pos. Code
ItemVrs. Serie
Pos. Code
ItemVrs. Serie
1 8270082 SCREW 5X16
2 8215074 SWITCH ASM582T
3 8219242 LABEL
4 8202792 HANDLE
5 8270083 SCREW 5X25
7 8202793 BRACKET
8 8268531 TERMINAL
9 8202794 COVER
10 8268532 CAPACITOR
11 8299649 FILTER
13 8202795 MOTOR COVER
14 8246453 CORD ASS’Y
15 8299648 FILTER
17 8202796 COVER
18 8268533 SHAKER
19 8202797 SPACER
20 8204290 UPPER JOINT
21 8268534 MOTOR
22 8204291 LOWER JOINT
23 8202798 RING
24 8202799 MOTOR BASE
25 8204292 JOINT
26 8268535 ELECTRONIC CIRCUIT
27 8277028 SCREW M.5X16
28 8268537 EARTH CONNECTOR
29 8268536 AUTO/MAN CIRCUIT
30 8268538 SOCKET
31 8270084 SCREW 3X10
32 8299650 TUBE
33 8268539 ALARM
34 8270085 SCREW 3.5X12
35 8223897 FENCE
36 8268540 PRESSURE SWITCH
38 8299651 FILTER SUPPORT
39 8270086 SCREW 5X12
40 8246454 HOOK
41 8202805 FILTER SUPPORT
42 8299653 INSERT
43 8204293 FELT JOINT
44 8289071 RIVET 4.8X17
45 8299647 FILTER ASM582T
47 8204294 FELT JOINT
48 8299652 FAN OUTLET
49 8299654 JOINT
50 8202806 WHEEL SUPPORT
51 8299655 WHEEL
53 8277029 SCREW
54 8299646 POLYESTER DUST BAG FOR ASM582T
55 8202807 CONNECTOR
56 8202804 BODY
57 8299658 PIPE WITH CONNECTORS
