PEB250 edgebander (Ref. 5000800)
Technical information
Explosion drawing and parts list
DP 131015E00
(*) Parts not mounted in the current version
Pos. Code
ItemVrs. Serie
Pos. Code
ItemVrs. Serie
120 6371025 HEX HD. SCREW M.4X12
121 6626089 SPRING
122 6675076 HEX. SOCKET SET SCREW M.5X25
124 7085008 HEX. NUT M.5
125 6689043 BALL D.6.35
126 7004004 RUBBER STOP
127 7070061 SCREW CE 4.2X13
128 7280036 WASHER D.8.2XD.19.9X1
129 8423195 WASHER D.6.3XD.15X1.5
130 8481013 WASHER
* 131 8512055 BUSHING D.8X10X12
132 8519197 VOLTAGE LABEL
133 8522492 TAPE GUIDE BUSHING
134 8578024 SCREW M.5X10 TORX
135 8578028 SCREW M.5X30 TORX (DIN 965)
136 8578029 SCREW M5X20 TORX
137 8578030 SCREW M4X8 TORX
138 8580072 WASHER
139 8585053 SPACER
140 8585063 NUT M15X100
141 8802480 HANDLE COVER
142 8802692 HANDLE
143 9075003 HEX. SOCKET HD. CAP SCREW M.8X35
144 9280063 WASHER D. 5.1X13X1.5
* 145 5087160 TIGHTENING PINION
* 146 5078032 C1 12800 SCREW 4X12 TORX
* 146 - 5078035 B0 12404 SCREW 4X6 TORX
* 146 - 5078032 SCREW 4X12 TORX
147 4385013 C0 12687 NUT M.5
148 5022691 C0 12687 ROLLER TIGHTENER
149 6622172 C0 12687 SPACER
150 5023969 C0 12687 SUPPORT
151 2280004 C0 12687 WASHER D.5.2X11.1X0.7
* 152 5578031 C0 12687 SCREW M5X10 TORX
153 1380024 C0 12687 WASHER 8.2X19X0.1
154 5004288 D1 12894 ROLLER
155 5022670 E0 13103 SHAFT
S/P 5077030 RING
S/P - 5046426 TEMPLATE BASE ASS’Y
