Appropriate Usage

The instrument may only be used under those conditions and for those purposes for which it

was conceived. For this reason, in particular the safety references , the technical data including

environmental conditions and the usage in dry environments must be followed.

When modifying or changing the instrument, the operational safety is no longer ensured.

Operation Elements and Connections

Transmitter

1) Terminal "+"

2) Terminal "ground"

3) LCD

4) Key Sensitivity Level

Repeated pressing allows selection between

three transmission levels.

5) Key ON/OFF

To switch off the instrument press the button for

approx. 2 seconds.

6) Battery case (backside)

6 a)Jumper for selectable Code (in battery case)

Standard setup is "Code F”
