Ariens ST28DLE PRO [35/42] Storage
![Ariens ST28DLE PRO [35/42] Storage](/views2/1509902/page35/bg23.png)
EN - 35
SHORT TERM
IMPORTANT: NEVER spray unit with high
pressure water or store unit outdoors.
Run with attachment clutch engaged a few
minutes after each use to free unit of any
loose or melting snow.
Close fuel shut-off valve.
Inspect unit for visible signs of wear,
breakage or damage.
Keep all nuts, bolts and screws properly
tightened and know unit is in safe working
condition.
Store unit in a cool, dry protected area.
LONG TERM
Clean unit thoroughly with mild soap and low
pressure water and lubricate (see
MAINTENANCE on page 24) Touch up all
scratched painted surfaces.
Remove weight from wheels by putting
blocks under frame or axle.
FUEL SYSTEM
Gasoline left in the fuel system for extended
periods without a stabilizer will deteriorate,
resulting in gum deposits in the system.
These deposits can damage the carburetor
and the fuel hoses, filter and tank. Prevent
deposits from forming in the fuel system
during storage by adding a quality fuel
stabilizer to the fuel. Follow the
recommended mix ratio found on the fuel
stabilizer container.
IMPORTANT: NEVER store the engine with
fuel in the fuel tank inside of a building with
potential sources of ignition.
Add Fuel Stabilizer
1. Turn the fuel valve off while engine is
running and allow the engine to run until
it stops. Turn engine OFF when it begins
surging to avoid engine damage.
2. Add fuel stabilizer, following the
manufacturer’s instructions.
3. Turn fuel valve on after adding fuel
stabilizer.
4. Re-start engine.
5. Run the engine outdoors for 5 minutes to
be sure that treated gasoline has
replaced the untreated gasoline in the
carburetor.
6. Slow the engine to an idle speed.
7. Repeat step 1 above.
STORAGE
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
SERVICE PARTS
Order the following parts through your
Dealer:
Part No. Description
00036800 Ariens Hi-Temp Grease
(3.3 oz cartridges )
00592900 Fuel Stabilizer (4 oz.)
21534100 Spark Plug (921023, 035)
21547400 Spark Plug
(921024, 028, 029, 030, 032)
07200514 Auger Belt (Set of 2)
(921023, 024, 030, 035)
07200536 Auger Belt (Set of 2)
(921028, 029, 032)
07200111 Traction Belt
(921024, 030, 035)
07200114 Traction Belt (921023)
07200522 Traction Belt
(921028, 029, 032)
00170800 Friction Disc
52100100 Shear Bolt Kit
06400920 Gear Case Seal Washer
72101100 Kit, Steel Skid Shoes
ACCESSORIES
See your authorized Ariens dealer to add
the additional accessories available to your
Sno-Thro.
Part No. Description
72406500 Front Weight Kit
72406900 Slicer Bar
72600300 Composite Skid Shoes
72601500 Cover
72408000 Snow Cab
72101400 Heated Hand Grips
(921023, 024, 030, 032, 035)
