1
English
ACCESSORIES
1 Dust container
2* Telescopic tube
3* Extension tube (2)
4 Hose handle + hose
5 Carpet/hardfloor nozzle
6* Parquet nozzle
7* Turbo nozzle
8a Combination nozzle
8b Upholstery nozzle
SAFETY PRECAUTIONS
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilit-
ies, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
The vacuum cleaner features double insulation and does not
need to be earthed.
Children should be supervised to ensure that they do not
play with the appliance.
Never vacuum :
• In wet areas.
• Close to flammable gases, etc.
• Without a dust container (this may damage the clean-
er). A safety device is fitted which prevents the cover to
close with out a dust container. Do not attempt to
force cover to close.
• Sharp objects.
• Fluids (this can cause serious damage to the machine).
• Hot or cold cinders, lit cigarette butts, etc.
• Fine dust from plaster, concrete, or ash, for example.
The above can cause serious damage to the motor –
damage which is not covered by the warranty.
Electrical cable precautions:
• Regularly check that the cable is not damaged. Never
use the vacuum cleaner if the cable is damaged.
• If the supply cord is damaged, it must be replaced by
the manufacturer, it’s service agent or similary quali-
fied person in order to avoid a hazard. Damage to
the cleaner cable will not be covered by the warranty.
• Never pull or lift the vacuum cleaner by the cable.
• Disconnect the plug from the wall socket before clean-
ing or maintaining the vacuum cleaner.
All service and repairs must be carried out by an authorised
Zanussi service centre. Always keep the vacuum cleaner in a
dry place.
BEFORE STARTING
(9.) Check that the dust container and motor filter are in
place.
(10.) Insert the hose until the catch clicks to engage (press
the catch to release the hose).
(11.) Attach the extension wand or telescopic wand (only on
certain models) to the hose handle and or nozzle (to
take them apart again, twist and pull).
(12.) Extend the cord and plug it into the wall socket. The
vacuum cleaner has an integrated cord winder. To re-
wind the cable press the foot pedal (take hold of the
plug to prevent it striking you).
(13.) Press the ON/OFF button to switch the appliance on.
(13./14.) Adjust suction power using the power control but-
ton on the vacuum cleaner or the suction control on
the hose handle.
(15.) A practical parking feature (as well as minimizing the
risk of breakage) makes things easier when pausing
during cleaning.
(16.) The parking feature makes it easier to move and store
the vacuum cleaner.
USE THE NOZZLES AS FOLLOWS:
Carpets: Use the carpet/hardfloor nozzle with the lever in
position (17). Reduce suction power for small carpets.
Hard floors: Use the carpet/hardfloor nozzle with the lever
in position (18).
Wooden floors: Use the parquet nozzle (certain models only, 6).
Special combined nozzle: Detach the nozzle from the acces-
ory dock and use it for bookshelves (with folding out of the
„brush” end) or crevices, corners (with the „crevice” end) (8a.)
Upholstery nozzle: Use the furniture nozzle (8b).
Curtains, lightweight fabrics, etc.: Use the furniture nozzle
(8b).
Reduce suction power if necessary.
Using the turbo nozzle (certain models only) (7)
(19.) Attach the nozzle to the tube.
Note: Do not use the power or turbo nozzle on fur rugs,
rugs with long fringes or a pile depth exceeding 15 mm. To
avoid damaging the carpet, do not keep the nozzle station-
ary whilst the brush is rotating. Do not pass the nozzle
across electric cables, and be sure to switch off the vacuum
cleaner immediately after use.
MAINTENANCE
REMOVING THE CONTENTS OF THE DUST CONTAINER
Never operate the cleaner without the dust container
installed.
The dust container must be emptied if the window of the
dust container indicator changes into red when the cleaner
is operating at maximum power and the nozzle is raised
from the floor.
21 Remove the dust container from the cleaner.
22 Remove the filter set from the dust container by taking
it in the way indicated in the icon.
23 Remove the contents of the dust container.
24 Each time you empty the dust container, check and
clean the two filters in the dust container lid.
22 Put the filter set back into the dust container.
21 Put the dust container back into the cleaner.
Replacing the motor filter
Should be done with every 10th emptying of the dust container.
1 Open the lid.
2 Remove the old filter (26).
3 Insert a new filter and close the lid.
1
2
3
4
5
6
7
8a
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
8b
* Depending on the model
