7.7. Cleaning the generating set
Important
Cleaning with a water jet is not recommended.
Cleaning with high pressure cleaning equipment is forbidden.
n Remove all dust and debris from around the exhaust
o Clean the generating set, particularly the alternator and engine air inlets and outlets, using a cloth and brush.
p Check the general condition of the generating set and replace any faulty parts
8. Storing the generating set
In case of prolonged non-usage of the generating set, carry out storage operations in accordance with the guidelines given below.
n Remove the carburetor draining screw and drain the fuel completely into an appropriate container.
o Run the engine till it stops due to lack of fuel.
p Close the fuel tank aeration pointer (fig. C – no. 1, OFF) and the fuel valve (fig. A – no. 3).
q Renew the engine oil.
r Remove the spark plug (fig. E – no. 2) and pour around 15ml of engine oil into the cylinder through the spark plug opening.
s Refit the spark plug.
t Pull the recoil starter handle 3 to 4 times (fig. A – no. 7) to completely drain-out the carburetor and distribute the oil inside the
cylinder.
u Clean the exterior of the generating set and cover it with the protection cover in order to protect it from dust.
v Store the generating set in a clean and dry spot.
9. Troubleshooting
Problems Probable cause Possible solutions
Load connected to the generating set while starting. Disconnect the load
The oil level is too low. Check the oil level and top up if necessary.
Fuel tank aeration pointer in
O
O
F
F
F
F position Place the pointer in
O
O
N
N position (fig. C – no. 1)
Insufficient fuel level Fill-up fuel (see § Filling with fuel)
Fuel feed system blocked or elusive Check, repair or replace.*
The engine does
not start
Air filter blocked Clean the air filter
Ventilation openings blocked Clean the suction and discharge guards
The oil level is too low. Check the oil level and top up if necessary.
The engine
stops
Overload indicator (fig. A – no. 11) turned on: overload.
Eliminate the overload and wait for 30sec before
restarting.
Defective device power supply cord. Change the cord.
Defective electrical socket. Check, repair or replace.*
No electric
current
Defective alternator. Check, repair or replace.*
* Operation(s) to be entrusted to one of our agents.
10. Specifications
Model NEO 2000
Type of Engine OLYMP ES 86-1
Rated output in Watts 1480 W
Direct Current 12V-5A
Alternating Current 230V-6.4V
Socket type 2 x 2P+T - 10/16A - 230V
Circuit-breaker ●
Oil cut-out ●
Battery X
Acoustic pressure level at 1 m in dB(A) 82 dB(A)
Weight in kg (without fuel) 21
Dimensions L x w x h in cm 54 x 28 x 46,5
Recommended oil SAE 15W40
Oil sump capacity in litres 0,5
Recommended fuel Unleaded petrol
Fuel tank capacity in litres 3,3
Spark plug LG : E7 RTC / NGK : BPR7HSA
● : standard o : optional X : not possible
