en If the depth of the adjacent kitchen equipment is more than 60 cm observe lateral minimum distances in order to utilise the full door opening angle Door opening angle Minimum distance 90 40 mm 135 140 mm Press the clamping ring in the direction of the arrow and simul taneously pull the hose out of the hose connection Remove cover plate from the top of the appliance To do this remove the 5 stoppers and unscrew the screws Unscrewing the refrigerator compartment door Unscrew the refrigerator compart ment door in the same way the refri gerator compartment door does not feature any electrical plug and socket connections or hose connections Warning Before installing the doors in reverse sequence ensure that the appliance is level in the installation location Connecting the appliance to the water supply If a panel or cupboard is installed above the appliance ensure that a gap is left so that the appliance can be pulled out of the recess if required The water may be connected only by a competent fitter according to the local regulations of the appropriate water supply company Unscrewing the doors Connect the appliance to a cold water line If the appliance will not fit through the house door the appliance doors can be unscrewed Minimum pressure 0 1 MPa 1 0 bar We recommend that installation is carried out by our customer service Maximum pressure up to 1 0 Mpa 10 0 bar Unscrewing the freezer compartment door Remove lower cover Depending on the local conditions it may be necessary to install a pressure reducer in the water line Loosen the hose connection Loosen the hose clips on the hose connection Disconnect the electrical plug and socket connections 2 The tap for connection of the enclosed line should be freely accessible The enclosed connection lines are 1 5 m and 7 m long Taste and odour of the water may be improved by installing the enclosed water filter in the water supply Electrical connection Connect the line to the solenoid valve While holding the door unscrew the hinge screws on top 3 Lift the door off the lower hinge pin Remove and deposit the door with care Do not damage the water line 36
