Ashly Audio NE 8250.10 [13/16] Технические характеристики

  -    NE

4)    DSP -   ""   

   DSP.   DSP,   ,

 ,    ,  , ,  

 .

5)   / -         .

          .   ,

        .

6)   -       ,  

 ,  .

7)    DSP -  DSP   ,   , 

  .

8)    Output Mute -  .

9)    Output Channel Name -      .

10) Output Channel Number - Right click on this to bring up Clear, Copy, Link, and Sub Preset functions for that output

channel.

6.  

   

Power Output

Stereo Mode, All Channels Driven

8 ohms, 20Hz-20kHz 1%THD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150W

4 ohms, 20Hz-20kHz 1%THD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250W

Bridge Mode

8 ohms, 20Hz-20kHz 1%THD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500W

25, 70, 100 Volt models, 20Hz-20kHz 1%THD, per channel . . . . . . . . . . . . . . . . . . . . . . 250W

Signal to Noise (20Hz-20KHz, unweighted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >98dB

Power Requirements (1/8 Power Pink Noise @4 Ohm): . . . . . . . . . . . . . . . . . . . . . . . . . . 360W - 8Ch, 200W - 4Ch

Distortion (SMPTE, typical) - 8 ohm load, 10dB below rated power: . . . . . . . . . . . . . . . <0.5%

Distortion (THD-N, typical) - 8 ohm load, 10dB below rated power, 20Hz-20kHz: . . . . <0.5%

Frequency Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Hz-20kHz, +/-1dB

Damping Factor (8 ohm load, <1kHz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >250

Input Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20K Ohm, balanced

Maximum Input Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +21dB

Cooling . . . . . . . . . . . . . . temperature dependent speed-controlled axial fan

Control Network . . . . . . . onboard, compatible with standard 100MB Ethernet hardware

Front Panel Indicators . . per channel: Clip/Mute, -6dB, -12dB, -18dB, Temp, Current, Bridge (per pair)

overall: Power, Standby, Protect, Power Switch Disable, Comm

Control Surface and Amp LEDs: Level meters are dB below RATED output

Attenuators: per channel: front panel, software, offset link group, and remote

Input Connections . . . . . Euroblock

Output Connections . . . . Euroblock

Amplifier Protection inrush current limitation, temperature monitoring, output over-current protection, mains fuses

Power Cable Connector 15A Edison

Dimensions . . . . . . . . . . . 19”W x 3.5”H x 15.5”D (483 x 89 x 394mm)

Weight . . . . . . . . . . . . . . . 21 lbs (9.53kg)

Environmental: . . . . . . . . 40-120 deg. F, (4-49 deg, C) noncondensing
