DESCRIPTION
DSR 9401 FTA / DSB-9401F / DSB-9401V
GB
DSR 9401 FTA / DSB-9401F / DSB-9401V
DESCRIPTION
GB-7GB-6
DIGITAL SATELLITE RECEIVER
1. AC MAINS This is to plug in the AC mains power cord.
The input AC voltage range is 100V to 240V, 50Hz/60Hz supply.
2. S/PDIF
Output for connection to a digital amplifier.
3. VCR SCART This is used to connect to your VCR.
4. TV SCART This is used to connect to your TV.
Rear PanelFront Panel
1. LED Display
When the LED light Red, the set-top box enters the
standby mode.
When the LED light Green, it enters the operation mode.
2. Card Slot
1 Slot for Viaccess smartcard. (For model DSB-9401V)
12
2 13
4
