5
6
USB operation
USB playback
• Insert a USB device into the USB A port
of the unit. Press the SOURCE button to
select the USB mode. The unit will start
reading the device and start playback if any
supported audio files are found.
• When the device and tracks on it are
detected, the display shows the currently
playing track number, track playback time and
operation mode in turn.
Playback operations
• During playback press the PLAY/PAUSE
button on the unit to pause playback. Press
this button again to resume playback.
• During playback press PREVIOUS/NEXT
buttons to go to a previous or a next track.
• During playback press the BASS button
to enable the enhanced bass playback. Press
this button again to disable it.
General USB notes
• This unit is equipped with a USB socket
that can read and play MP3 files stored on
standard USB flash (compatible with USB
version 2.0) up to 32 GB.
Always switch off the unit or change
mode to another one before removing a USB
flash drive to prevent damage to your USB
device.
Note: Although this product is fully
compatible with USB 2.0 standard, a small
percentage of USB flash drives might not be
readable, due to those device manufacturers’
non-compliance with the full (official) USB
standards.
• FAT/FAT32 file system are supported.
According to the USB 1.1/2.0
Standard, usage of a USB device with power
current consumption exceeding 500 mA is not
recommended without supplementary power
supply.
Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.
Warning: use of external USB drives
containing BIN files in root directory may cause
malfunction of unit or damage to the software.
• During playback press the AUTO DJ
and DJ EFFECT buttons to switch between
and apply various sound effects.
USB charging
• The USB B port is used to charge the
battery of any supported (DC 5V 2.1A)
external device from this unit.
• You cannot play music from devices
connected to the USB B port.
Radio operation
• Press the SOURCE button repeatedly
to select the RADIO (FM) mode.
• For FM reception extend the FM antenna.
• Press and hold the PLAY/PAUSE button
to automatically scan for available broadcasting
channels, press this button again to stop
scanning.
• Shortly press the PLAY/PAUSE button
to switch between preset station and frequency
selection.
• Shortly press the NEXT button to jump
to the next preset station. Press and hold this
button to manually increase (fine-tune) the
radio frequency.
• Shortly press the PREVIOUS button to
jump to the previous preset station. Press
and hold this button to manually decrease
(fine-tune) the radio frequency.
Note: in RADIO mode you can adjust the
volume, equalizer and bass as usual.
